1202G15 SNR B 11.000 mm 15x35x11mm  Self aligning ball bearings

1202G15 SNR B 11.000 mm 15x35x11mm Self aligning ball bearings

d120.2 mmD128.8 mmrs min0.6 mme0.34 Y11.86 Y22.89 Y01.95 Radial clearance classCN Precision classP0 Mass0.05 kgDynamic load, C7.5 kNStatic load, C01.75 kNNref18.000 rpmNlim28.000 rpmMin operating temperature, Tmin-20 °CMax operating temperature, Tmax120 °CCharacteristic cage frequency, FTF0.39 HzCharacteristic rolling element frequency, BSF4.18 H…
Contact Us Now !

Product description

1202G15 SNR B 11.000 mm 15x35x11mm Self aligning ball bearings

d120.2 mm
D128.8 mm
rs min0.6 mm
e0.34
Y11.86
Y22.89
Y01.95
Radial clearance classCN
Precision classP0
Mass0.05 kg
Dynamic load, C7.5 kN
Static load, C01.75 kN
Nref18.000 rpm
Nlim28.000 rpm
Min operating temperature, Tmin-20 °C
Max operating temperature, Tmax120 °C
Characteristic cage frequency, FTF0.39 Hz
Characteristic rolling element frequency, BSF4.18 Hz
Characteristic outer ring frequency, BPF03.89 Hz
Characteristic inner ring frequency, BPFI6.11 Hz
da min19 mm
Da max31 mm
ra max0.6 mm
Bearing number1202G15
Size (mm)15x35x11
BrandSNR
Bore Diameter (mm)15.000
Outer Diameter (mm)35.000
Width (mm)11.000
d15.000 mm
D35.000 mm
B11.000 mm
C11.000 mm
