16056 MA SKF 420x280x44mm  Noun Bearing Deep groove ball bearings

16056 MA SKF 420x280x44mm Noun Bearing Deep groove ball bearings

Bearing number16056 MASize (mm)420x280x44BrandSKFBore Diameter (mm)420Outer Diameter (mm)280Width (mm)44d280 mmD420 mmB44 mmd1327.2 mmD1374 mmr1,2 - min.3 mmda - min.293 mmDa - max.407 mmra - max.2.5 mmBasic dynamic load rating - C242 kNBasic static load rating - C0335 kNFatigue load limit - Pu7.5 kNReference speed3000 r/minLimiting speed2600 r/min…
Contact Us Now !

Product description

16056 MA SKF 420x280x44mm Noun Bearing Deep groove ball bearings

Bearing number 16056 MA
Size (mm) 420x280x44
Brand SKF
Bore Diameter (mm) 420
Outer Diameter (mm) 280
Width (mm) 44
d 280 mm
D 420 mm
B 44 mm
d1 327.2 mm
D1 374 mm
r1,2 – min. 3 mm
da – min. 293 mm
Da – max. 407 mm
ra – max. 2.5 mm
Basic dynamic load rating – C 242 kN
Basic static load rating – C0 335 kN
Fatigue load limit – Pu 7.5 kN
Reference speed 3000 r/min
Limiting speed 2600 r/min
Calculation factor – kr 0.02
Calculation factor – f0 16.5
Category Single Row Ball Bearings
BDI Inventory 0.0
Manufacturer Name SKF
Minimum Buy Quantity N/A
Weight / Kilogram 23.908
EAN 7316577029256
Product Group – BDI B00308
Enclosure Open
Precision Class ABEC 1 | ISO P0
Maximum Capacity / Filling Slot No
Rolling Element Ball Bearing
Snap Ring No
Internal Special Features No
Cage Material Brass
Internal Clearance C0-Medium
Inch – Metric Metric
Long Description 280MM Bore; 420MM Outside Diameter; 44MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
Category – BDI Single Row Ball Bearing
UNSPSC 31171504
Harmonized Tariff Code 8482.10.50.68
Noun Bearing
Keyword String Ball
Manufacturer URL http://www.skf.com
Manufacturer Item Number 16056 MA
Weight / LBS 52.661
Bore 11.024 Inch | 280 Millimeter
Outside Diameter 16.535 Inch | 420 Millimeter
Outer Race Width 1.732 Inch | 44 Millimeter
d1 327.2 mm
D1 374 mm
r1,2 min. 3 mm
da min. 293 mm
Da max. 407 mm
ra max. 2.5 mm
Basic dynamic load rating C 242 kN
Basic static load rating C0 335 kN
Fatigue load limit Pu 7.5 kN
Calculation factor kr 0.02
Calculation factor f0 16.5
Mass bearing 23.6 kg
