Home > Spherical roller bearings > 22214 E SKF internal clearance: C0 125x70x31mm Spherical roller bearings
22214 E SKF internal clearance: C0 125x70x31mm  Spherical roller bearings

22214 E SKF internal clearance: C0 125x70x31mm Spherical roller bearings

Bearing number22214 ESize (mm)125x70x31BrandSKFBore Diameter (mm)125Outer Diameter (mm)70Width (mm)31d70 mmD125 mmB31 mmd283 mmD1111 mmb6 mmK3 mmr1,2 - min.1.5 mmda - min.79 mmDa - max.116 mmra - max.1.5 mmBasic dynamic load rating - C213 kNBasic static load rating - C0228 kNFatigue load limit - Pu25.5 kNReference speed5000 r/minLimiting speed6700 …
Contact Us Now !

Product description

22214 E SKF internal clearance: C0 125x70x31mm Spherical roller bearings

Bearing number 22214 E
Size (mm) 125x70x31
Brand SKF
Bore Diameter (mm) 125
Outer Diameter (mm) 70
Width (mm) 31
d 70 mm
D 125 mm
B 31 mm
d2 83 mm
D1 111 mm
b 6 mm
K 3 mm
r1,2 – min. 1.5 mm
da – min. 79 mm
Da – max. 116 mm
ra – max. 1.5 mm
Basic dynamic load rating – C 213 kN
Basic static load rating – C0 228 kN
Fatigue load limit – Pu 25.5 kN
Reference speed 5000 r/min
Limiting speed 6700 r/min
Calculation factor – e 0.23
Calculation factor – Y1 2.9
Calculation factor – Y2 4.4
Calculation factor – Y0 2.8
Category Spherical Roller Bearings
BDI Inventory 0.0
Manufacturer Name SKF
Minimum Buy Quantity N/A
Weight / Kilogram 1.651
EAN 7316576652356
Product Group – BDI B04311
Internal Clearance C0-Medium
Mounting Method Shaft Mount
Rolling Element Spherical Roller Bearing
Bore Profile Straight
Cage Material Steel
Enclosure Open
Number of Rows of Rollers Double Row
Relubricatable Yes
Withdrawal Sleeve Not Applicable
Withdrawal Nut Not Applicable
Inch – Metric Metric
Long Description 70MM Straight Bore; 125MM Outside Diameter; 31MM Width; C0-Medium Clearance; Shaft Mount; Double Row of Spherical Roller Bearings; Steel Cage Material; Open Enclosure; Relubricatable
Category – BDI Spherical Roller Bearing
UNSPSC 31171510
Harmonized Tariff Code 84823080
Noun Bearing
Keyword String Spherical
Manufacturer URL http://www.skf.com
Weight / LBS 3.637
Width 1.22 Inch | 31 Millimeter
Outside Diameter 4.921 Inch | 125 Millimeter
Bore 2.756 Inch | 70 Millimeter
Adapter Part Number Not Applicable Inch | Not Applicable Millimeter
bore diameter: 70 mm
maximum rpm: 6700 RPM
outside diameter: 125 mm
operating temperature range: Maximum of +390 °F
overall width: 31 mm
cage material: Steel
bore type: Straight
bearing material: Steel
outer ring type: Not Split
precision rating: Not Rated
internal clearance: C0
finish/coating: Uncoated
closure type: Open
outer ring width: 31 mm
lubrication hole type: Lubrication Groove & Hole
fillet radius: 1.5 mm
dynamic load capacity: 208 kN
series: 222
static load capacity: 228 kN
d2 83 mm
D1 111 mm
r1,2 min. 1.5 mm
da min. 79 mm
Da max. 116 mm
ra max. 1.5 mm
Basic dynamic load rating C 213 kN
Basic static load rating C0 228 kN
Fatigue load limit Pu 25.5 kN
Calculation factor e 0.23
Calculation factor Y1 2.9
Calculation factor Y2 4.4
Calculation factor Y0 2.8
Mass bearing 1.55 kg
