AST20 WC22 AST  Material Carbon steel shell with POM plastic liner Plain bearings

AST20 WC22 AST Material Carbon steel shell with POM plastic liner Plain bearings

Bearing numberAST20 WC22BrandASTBore Diameter (mm)20Outer Diameter (mm)38Bearing Typethrust washerShaft Dia., Nominal (d)20.0000Bearing Outside Diameter, Nominal(Do)38.000Washer Inside Diameter, Nominal (di)22Washer Inside Diameter Tolerance (di tol.) - +0.25 / -0+0.25 / 0Washer Outside Diameter, Nominal (Do)38Washer Outside Diameter Tolerance (Do …
Contact Us Now !

Product description

AST20 WC22 AST Material Carbon steel shell with POM plastic liner Plain bearings

Bearing number AST20 WC22
Brand AST
Bore Diameter (mm) 20
Outer Diameter (mm) 38
Bearing Type thrust washer
Shaft Dia., Nominal (d) 20.0000
Bearing Outside Diameter, Nominal(Do) 38.000
Washer Inside Diameter, Nominal (di) 22
Washer Inside Diameter Tolerance (di tol.) – +0.25 / -0 +0.25 / 0
Washer Outside Diameter, Nominal (Do) 38
Washer Outside Diameter Tolerance (Do tol.) – +0 / -0.25 +0 / 0.25
Washer Thickness, Nominal (S3) 2
Washer Thickness Tolerance (S3 tol.) – +0 / -0.05 +0 / 0.05
Mounting Hole Dia. (dm) 3.000
Mounting Hole Pitch Dia. (dp) 30
Housing Counterbore Depth (Ha) 1.00
Housing Counterbore Depth Tolerance (Ha tol.) – +0.2 / -0.2 +0.2 / 0.2
Housing Counterbore Diameter, Nominal (HD) 38.000
Housing Counterbore Diameter Tolerance (HD tol.) +0.12 / 0
Material Carbon steel shell with POM plastic liner

Cross-reference to other manufacturer’s part number

712147210 Needle roller bearings

Width :8mm , d:46 mm , D:63 mm , T:8 mm
PSL 611-9 Tapered roller bearings

(Grease) Lubrication Speed:900 r/min , (Oil) Lubrication Speed:1300 r/min , Calculation factor (Y):1.4 , Calculation factor (e):0.43
203KRR2 C3 Deep groove ball bearings

d:16.2 mm , Outer Diameter :40mm , Width :18.2mm , Bore Diameter :16.2mm , B:18.2 mm , D:40 mm
29296 Thrust roller bearings

Minimum axial load factor A:13 , Basic static load rating C0:11800 kN , Mass bearing:98 kg , Fatigue load limit Pu:950 kN
ESFEE205 Bearing units

A2:32.9 mm , Thread (G):R1/8" , Basic dynamic load rating (C):14 kN , N:9 mm , Weight:0.8 Kg
FSYE 3 11/16 Bearing units

Attachment bolt diameter G:19.05 mm , J min.:304.8 mm , J max.:333.375 mm , Basic dynamic load rating C:311 kN , Mass bearing unit:22.9 kg , J1:57.15 mm
K81209TN Thrust roller bearings

Dw:9 mm , d:45 mm , Width :48mm , D:73 mm , T:48 mm
FY 1.3/16 FM Bearing units

End cover:
ECY 206
, Recommended diameter for attachment bolts, mm G:10 mm , Recommended tightening torque for grub screw:6.5 N·m , Bearing:
YET 206-103
, Recommended diameter for attachment bolts, inch G:0.375 in , Housing:
FY 506 M
EXFL307 Bearing units

Weight:1.8 Kg , Thread (G):M6x1 , N:23 mm , A2:53.3 mm , Basic dynamic load rating (C):33.5 kN
UKFL218 Bearing units

L:68 mm , E:265 mm , F:40 mm , S:25 mm , G:24 mm , Bolt (G):M22
