EXSP205 SNR  H1 41 mm Bearing units

EXSP205 SNR H1 41 mm Bearing units

B34.8 mmA517.4 mmd137.4 mmGR1/8" H241 mms130.9 mmS17.4 mmSW3 mmC14 kNC07.88 kNT min.-20 °CT max.100 °CRecommended tightening torque for set screw5.5 NmDesignation of housingSP203-205/52- Designation of bearingEX205G2 Bearing numberEXSP205BrandSNRBore Diameter (mm)25d25 mms17.4 mmA21 mmB144.3 mmD238.1 mmH78 mmH141 mmL264 mmL1225 mmThread (G)R1/8&q…
Contact Us Now !

Product description

EXSP205 SNR H1 41 mm Bearing units

B34.8 mm
A517.4 mm
d137.4 mm
GR1/8″
H241 mm
s130.9 mm
S17.4 mm
SW3 mm
C14 kN
C07.88 kN
T min.-20 °C
T max.100 °C
Recommended tightening torque for set screw5.5 Nm
Designation of housingSP203-205/52-
Designation of bearingEX205G2
Bearing numberEXSP205
BrandSNR
Bore Diameter (mm)25
d25 mm
s17.4 mm
A21 mm
B144.3 mm
D238.1 mm
H78 mm
H141 mm
L264 mm
L1225 mm
Thread (G)R1/8"
Weight1.8 Kg
Basic dynamic load rating (C)14 kN
