EXT319 SNR J1 35 mm Bearing units

A272 mmB93.7 mmA546.9 mmd1140 mmGM10x1 H2165 mmN2106 mms183.35 mmS46.8 mmSW10 mmC156 kNC0122 kNT min.-20 Â°CT max.100 Â°CRecommended tightening torque for set screw120 NmDesignation of housingT319- Designation of bearingEX319G2 Bearing numberEXT319BrandSNRBore Diameter (mm)95d95 mmL4180 mmL546 mmL233 mmL3197 mms46.8 mmA110 mmA172 mmB1122.3 mmD2140 …

Product description

EXT319 SNR J1 35 mm Bearing units

A2	72 mm
B	93.7 mm
A5	46.9 mm
d1	140 mm
G	M10x1
H2	165 mm
N2	106 mm
s1	83.35 mm
S	46.8 mm
SW	10 mm
C	156 kN
C0	122 kN
T min.	-20 Â°C
T max.	100 Â°C
Recommended tightening torque for set screw	120 Nm
Designation of housing	T319-
Designation of bearing	EX319G2
Bearing number	EXT319
Brand	SNR
Bore Diameter (mm)	95
d	95 mm
L4	180 mm
L5	46 mm
L2	33 mm
L3	197 mm
s	46.8 mm
A	110 mm
A1	72 mm
B1	122.3 mm
D2	140 mm
H	270 mm
H1	165 mm
L	322 mm
L1	107 mm
N	57 mm
N1	106 mm
Thread (G)	M10x1
J1	35 mm
J2	240 mm
Weight	27.4 Kg
Basic dynamic load rating (C)	156 kN
