FY 1.1/4 FM SKF  Limiting speed 5300 r/min Bearing units

FY 1.1/4 FM SKF Limiting speed 5300 r/min Bearing units

Bearing numberFY 1.1/4 FMBrandSKFBore Diameter (mm)31.75d31.75 mms129.4 mmA134.5 mmB138.9 mmG12 mmJ92 mmL118 mmT50.4 mmA213 mmWeight1.55 KgBasic dynamic load rating (C)25.5 kNBasic static load rating (C0)15.3 kNFatigue load limit (Pu)0.655CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram1.6EAN…
Contact Us Now !

Product description

FY 1.1/4 FM SKF Limiting speed 5300 r/min Bearing units

Bearing number FY 1.1/4 FM
Brand SKF
Bore Diameter (mm) 31.75
d 31.75 mm
s1 29.4 mm
A1 34.5 mm
B1 38.9 mm
G 12 mm
J 92 mm
L 118 mm
T 50.4 mm
A2 13 mm
Weight 1.55 Kg
Basic dynamic load rating (C) 25.5 kN
Basic static load rating (C0) 15.3 kN
Fatigue load limit (Pu) 0.655
Category Flange Block Bearings
BDI Inventory 0.0
Manufacturer Name SKF
Minimum Buy Quantity N/A
Weight / Kilogram 1.6
EAN 7316576615016
Product Group – BDI M06110
Number of Mounting Holes 4
Mounting Method Eccentric Collar
Housing Style 4 Bolt Square Flange Block
Rolling Element Ball Bearing
Housing Material Cast Iron
Expansion / Non-expansion Non-expansion
Mounting Bolts 1/2 Inch
Relubricatable Yes
Insert Part Number YET 207-104
Seals M Seal
Housing Configuration 1 Piece Solid
Pilot Configuration No Pilot
Inch – Metric Inch
Long Description 4 Bolt Square Flange Block; 1-1/4" Bore; 5.1" Bolt Circle; 3-5/8" Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Iron; Ball Bearing; 1-17/32" Length Thru Bore; Relubricatable; M Seal Seals
Other Features Single Row | Standard Duty | Narrow Inner Race | Open End | Y Bearing
Category – BDI Flange Block
UNSPSC 31171501
Harmonized Tariff Code 8483.20.40.40
Noun Bearing
Keyword String Flanged
Manufacturer URL http://www.skf.com
Manufacturer Item Number FY 1.1/4 FM
Weight / LBS 3.53
Nominal Bolt Circle Diameter Round 5.1 Inch | 130 Millimeter
Bore 1.25 Inch | 31.75 Millimeter
Cartridge Pilot Diameter 0 Inch | 0 Millimeter
Length Thru Bore 1.531 Inch | 38.9 Millimeter
Bolt Spacing 3.625 Inch | 92.08 Millimeter
Cartridge Pilot Depth 0 Inch | 0 Millimeter
Housing material Cast iron
Da 106.4 mm
Db1 87 mm
Db2 95 mm
A 34.5 mm
A1 13 mm
A3 3.2 mm
A5 24.5 mm
B1 38.9 mm
N 14 mm
s1 29.4 mm
RG 1/4-28 UNF
R1 22.5 mm
DN 6.5 mm
SWN 7 mm
GN 1/4-28 SAE-LT
J6 106 mm
J7 29 mm
N4 4 mm
Basic dynamic load rating C 25.5 kN
Basic static load rating C0 15.3 kN
Fatigue load limit Pu 0.655 kN
Limiting speed 5300 r/min
Mass bearing unit 1.35 kg
Thread grub screw G2 3/8-24 UNF
Hexagonal key size for grub screw N 4.763 mm
Recommended tightening torque for grub screw 16.5 N·m
Recommended diameter for attachment bolts, mm G 12 mm
Recommended diameter for attachment bolts, inch G 0.5 in
Housing
Bearing
End cover
