FY 7/8 TF SKF Category – BDI Flange Block  Bearing units

FY 7/8 TF SKF Category – BDI Flange Block Bearing units

Bearing numberFY 7/8 TFBrandSKFBore Diameter (mm)22.225Width (mm)34.1d22.225 mms119.8 mmA130 mmB34.1 mmG10 mmJ70 mmL95 mmT38.8 mmA212 mmWeight0.8 KgBasic dynamic load rating (C)14 kNBasic static load rating (C0)7.8 kNFatigue load limit (Pu)0.335CategoryFlange Block BearingsBDI Inventory0.0Manufacturer NameSKFMinimum Buy QuantityN/AWeight / Kilogram…
Contact Us Now !

Product description

FY 7/8 TF SKF Category – BDI Flange Block Bearing units

Bearing numberFY 7/8 TF
BrandSKF
Bore Diameter (mm)22.225
Width (mm)34.1
d22.225 mm
s119.8 mm
A130 mm
B34.1 mm
G10 mm
J70 mm
L95 mm
T38.8 mm
A212 mm
Weight0.8 Kg
Basic dynamic load rating (C)14 kN
Basic static load rating (C0)7.8 kN
Fatigue load limit (Pu)0.335
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.858
EAN7316577754851
Product Group – BDIM06110
Number of Mounting Holes4
Mounting MethodSet Screw
Housing Style4 Bolt Square Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts7/16 Inch
RelubricatableYes
Insert Part NumberYAR 205-014-2F
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description4 Bolt Square Flange Block; 7/8" Bore; 4" Bolt Circle; 2-3/4" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 1-11/32" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFY 7/8 TF
Weight / LBS1.9
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Length Thru Bore1.344 Inch | 34.13 Millimeter
Nominal Bolt Circle Diameter Round4 Inch | 101.6 Millimeter
Bore0.875 Inch | 22.225 Millimeter
Bolt Spacing2.75 Inch | 69.85 Millimeter
Housing materialCast iron
Da74.6 mm
Db165 mm
Db271 mm
A30 mm
A112 mm
A33.2 mm
A520.5 mm
N11.5 mm
s119.8 mm
RG1/4-28 UNF
R121 mm
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J683 mm
J719 mm
N44 mm
Basic dynamic load rating C14 kN
Basic static load rating C07.8 kN
Fatigue load limit Pu0.335 kN
Limiting speed7000 r/min
Mass bearing unit0.74 kg
Thread grub screw G21/4-28 UNF
Hexagonal key size for grub screw N3.175 mm
Recommended tightening torque for grub screw4 N·m
Recommended diameter for attachment bolts, mm G10 mm
Recommended diameter for attachment bolts, inch G0.375 in
Housing
Bearing
End cover
