Plasma 200mm Z Axis NEMA23 LINEAR BEARING CNC

Home Improvement>Building & Hardware>Paint & Varnish>Other Paint & Varnish

Plasma 200mm Z Axis NEMA23 LINEAR BEARING CNC

Plasma Z Axis, Nema 23  – Supplied Assembled and tested – 200mm (8″)stroke



Our Part Number: Z-200-TR10X2 (x4 LM16UU)



 Chrome Shafting, 16mm Linear Bearings, Linear translation by Trapezoidal spindle assembled with Delrin nut.

Ø20mm Proxxon or 43mm Kress Motor Mount.



Unlike many pre-Assembled Z axis we offer an additional flange bearing assembled to the top yoke, this prevents unnecessary strain on the stepper motor bearings.

The stepper motor and trapezoidal spindle are connected via a coupling within the Nema 23 motor mount, supplied with end caps.

x4pcs Steel recirculating  linear bearings are assembled within the Z axis housing, running over Ø16mm Chrome Plated Anti-Corrosion resistant shafting, The IGUS bearings are further protected by end caps.

Translation is via a Trapezoidal spindle assembeld with a Derin nut, minimum backlash.

spindle mount is assembled to the bottom yoke. WE CAN OFFER TO MANUFACTURE SPINDLE MOUNTS TO SUIT YOUR MILLING SPINDLE.

Stepper motor coupling





Stepper motor is not included in the offer! we can supply from stock, please ask….



Z Axis: http://www.marchantdice.com/forum/viewtopic.php?t=477

Manufactured in the Uk by Marchant Dice Ltd (worldofcnc). Designed for use with our TR range of Desktop CNC Machines



Nema 23 Motor Mount: Manufactured from aluminiun extrusion, pre-machined for Nema 23 stepper motors, x4 M5*1.0mm fixings. Supplied with coupling and end caps.



Chrome Shafting: WV16(h6) x2pcs Chrome Plated Induction Hardened Anti-corrosion and Precision Ground Round Rails / shafting: http://www.marchantdice.com/worldofcnc/pdf/round_rail_wv.pdf designed for use with our SC__UU housings and LME linear bearings.



Linear Bearings: x4pcs LM16UU



Trapezoidal Spindle: TR10x2 Ø10mm Right hand thread (D) – (1 revolution = 2.0mm) Manufactured from C35E steel to a 7e tolerance, buttress thread form.:

http://www.marchantdice.com/worldofcnc/pdf/trap_spindle.pdf We also offer Corrosion resistant spindles: Stainless Steel (TRI) and multi-start.



Trapezoidal Delrin Nut: LKM Ø10×2mm Right hand Single Start thread (D) – (1 revolution x 2.0mm) Manufactured from Delrin, buttress thread form.:

http://www.marchantdice.com/worldofcnc/pdf/LKM.pdf .



Motor Mount: Proxxon Ø20.0mm or Kress Ø43.0mm motor mount with 90mm centres.



Stepper motor coupling: SRD25 10 x ? please select the diameter of your stepper motor spindle?



Manufactured in the UK by Marchant Dice Ltd (worldofcnc)
