SSR 8 ISB C 9 mm 8x22x12mm  Plain bearings

SSR 8 ISB C 9 mm 8x22x12mm Plain bearings

Bearing numberSSR 8Size (mm)8x22x12BrandISBBore Diameter (mm)8Outer Diameter (mm)22Width (mm)12d8 mmD22 mmB12 mmC9 mmr1 min.0.3 mmr2 min.0.3 mmA10.04 mmD115.88 mmS1.5 mmAngle14 °Weight0.024 KgBasic dynamic load rating (C)6.8 kN Cross-reference to other manufacturer's part number 2208 Self aligning ball bearingsBasic dynamic load rating (C):22.4…
Contact Us Now !

Product description

SSR 8 ISB C 9 mm 8x22x12mm Plain bearings

Bearing numberSSR 8
Size (mm)8x22x12
BrandISB
Bore Diameter (mm)8
Outer Diameter (mm)22
Width (mm)12
d8 mm
D22 mm
B12 mm
C9 mm
r1 min.0.3 mm
r2 min.0.3 mm
A10.04 mm
D115.88 mm
S1.5 mm
Angle14 °
Weight0.024 Kg
Basic dynamic load rating (C)6.8 kN

Cross-reference to other manufacturer’s part number

2208 Self aligning ball bearings

Basic dynamic load rating (C):22.4 kN , Weight:0.505 Kg , (Grease) Lubrication Speed:7600 r/min , Basic static load rating (C0):7.4 kN
TUP1 45.25 Plain bearings

D:50 mm , f1:1.2 mm , f2:0.6 mm , L:25 mm
ALF202-10 Bearing units

Basic static load rating (C0):4.8 kN , S:6 mm , Weight:0.28 Kg , Basic dynamic load rating (C):9.55 kN , A2:9.5 mm , Bolt (G):M6
24196ECA/W33 Spherical roller bearings

Calculation factor (e):0.37 , Calculation factor (Y1):1.8 , Reference speed:260 r/min , Calculation factor (Y0):1.8 , Limiting speed:400 r/min
AST090 10560 Plain bearings

ID Chamfer Length (Ci):0.600 , Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40 , OD Chamfer Length (Co):1.800 , ID Chamfer Angle (B deg.):45 , Material:Wrapped bronze with formed lubrication indents.
170RT93 Cylindrical roller bearings

E:325 mm , B:139.7 mm , r max:3 mm , C:139.7 mm
LBE 16 Linear bearings

Weight (g):47.00 , Groove Width (C2):1.600 , Material:52100 chrome steel. or equivalent , Groove Dia. (D1):25.000 , Groove-to-groove length (C1):22.000
AST650 101420 Plain bearings

OD Chamfer Length (Co):2.000 , ID Chamfer Length (Ci):1.200 , ID Chamfer Angle (B deg.):15 , Bearing Length Tolerance (B tol.) – -0.10 / -0.30:0.10 / 0.30 , Material:Cast bronze with solid lubricant inserts.
00050/00150 Tapered roller bearings

Basic dynamic load rating (C1):19.3 kN , Basic dynamic load rating (C90):5.01 , Calculation factor (e):0.28 , Basic dynamic load rating (Ca90):2.36
LMEFM20 Linear bearings

Tolerance perpendicularity (C):17 , â„“:36 Tolerance h14 , Basic dynamic load rating (C):1.4 kN , Weight:0.26 Kg
