YRT150 INA 150x240x12mm  a 6.2 mm Complex bearings

YRT150 INA 150x240x12mm a 6.2 mm Complex bearings

Bearing numberYRT150Size (mm)150x240x12BrandINABore Diameter (mm)150Outer Diameter (mm)240Width (mm)12d150 mmD240 mmC12 mmH40 mma6.2 mmd17 mmd211 mmd37 mmD1214 mmH126 mmH214 mmJ165 mmJ1225 mmWeight6.2 KgDynamic load rating radial (C)77 kNDynamic load rating axial (C)85 kNStatic load rating radial (C0)179 kNStatic load rating axial (C0)510 kNCategor…
Contact Us Now !

Product description

YRT150 INA 150x240x12mm a 6.2 mm Complex bearings

Bearing number YRT150
Size (mm) 150x240x12
Brand INA
Bore Diameter (mm) 150
Outer Diameter (mm) 240
Width (mm) 12
d 150 mm
D 240 mm
C 12 mm
H 40 mm
a 6.2 mm
d1 7 mm
d2 11 mm
d3 7 mm
D1 214 mm
H1 26 mm
H2 14 mm
J 165 mm
J1 225 mm
Weight 6.2 Kg
Dynamic load rating radial (C) 77 kN
Dynamic load rating axial (C) 85 kN
Static load rating radial (C0) 179 kN
Static load rating axial (C0) 510 kN
Category Bearings
BDI Inventory 0.0
Manufacturer Name SCHAEFFLER GROUP
Minimum Buy Quantity N/A
Weight / Kilogram 7.424
Product Group – BDI B00234

Cross-reference to other manufacturer’s part number

24122AXK30 Cylindrical roller bearings

Basic static load rating (C0):654 kN , (Oil) Lubrication Speed:3600 r/min , Calculation factor (Y1):1.8 , (Grease) Lubrication Speed:2700 r/min , Calculation factor (Y0):1.76 , Calculation factor (e):0.37
2TS2-DF0785LLA4X-GCS33/L417 Angular contact ball bearings

D:50.000 mm , C:20.000 mm , Width :20.000mm , B:20.000 mm , d:35.000 mm
SL014924 Cylindrical roller bearings

Weight:2.95 Kg , D1:148.6 mm , Basic dynamic load rating (C):228 kN , Basic static load rating (C0):455 kN , C:45 mm , d1:138.6 mm
20230 KC Spherical roller bearings

(Grease) Lubrication Speed:1000 r/min , Basic dynamic load rating (C):430 kN , Basic static load rating (C0):610 kN , Weight:11.5 Kg
S51208 Thrust ball bearings

d:40 mm , Basic dynamic load rating (C):46.5 kN , Basic static load rating (C0):98 kN , (Grease) Lubrication Speed:2900 r/min , D:68 mm , H:19 mm
KGNS 12 C-PP-AS Linear bearings

H2:18 mm , Basic dynamic load rating (C):0.78 kN , Weight:0.1 Kg , C2:23 mm
KBL0845-PP Linear bearings

Weight:0.031 Kg , L:45 mm , Basic dynamic load rating (C):0.431 kN , W:1.1 mm , L1:33 mm
TUP2 160.80 Plain bearings

L:80 mm , f1:1.6 mm , f2:0.8 mm , θ:11 mm
Y268 Needle roller bearings

D:50.8 mm , Weight:0.054 Kg , Fw:41.275 mm , Basic dynamic load rating (C):20.9 kN , Basic static load rating (C0):41 kN , C:12.7 mm
VEX 6 7CE3 Angular contact ball bearings

(Grease) Lubrication Speed:127 000 r/min , Basic static load rating (C0):0.49 kN , (Oil) Lubrication Speed:195 000 r/min , Basic dynamic load rating (C):1.51 kN
