09074/09194 KOYO  Basic static load rating (C0) 37.7 kN Tapered roller bearings

09074/09194 KOYO Basic static load rating (C0) 37.7 kN Tapered roller bearings

Bearing number09074/09194BrandKOYOBore Diameter (mm)19.05Width (mm)21.539d19.05 mmT23.02 mmB21.539 mmC17.462 mma13.8 mmr min.)SP1 mmr1 min.3.6 mmDa39 mmdb24 mmda26 mmDb44.5 mmBasic dynamic load rating (C)37.7 kNBasic static load rating (C0)37.7 kNCalculation factor (e)0.27Calculation factor (Y0)1.24 Cross-reference to other manufacturer's part numb…
Contact Us Now !

Product description

09074/09194 KOYO Basic static load rating (C0) 37.7 kN Tapered roller bearings

Bearing number09074/09194
BrandKOYO
Bore Diameter (mm)19.05
Width (mm)21.539
d19.05 mm
T23.02 mm
B21.539 mm
C17.462 mm
a13.8 mm
r min.)SP1 mm
r1 min.3.6 mm
Da39 mm
db24 mm
da26 mm
Db44.5 mm
Basic dynamic load rating (C)37.7 kN
Basic static load rating (C0)37.7 kN
Calculation factor (e)0.27
Calculation factor (Y0)1.24

Cross-reference to other manufacturer’s part number

T.P.N. 397 Plain bearings

Weight:79.50 Kg , Basic dynamic load rating (C):950 kN , C1:85 mm , Angle:6 °
02476/02420A Tapered roller bearings

C:16.238 mm , T:21 mm , B:22.225 mm , D:68.262 mm , R:0.8 mm , r:1.5 mm
AXK6085 Needle roller bearings

Washer designation Housing piloted:GS.81112 , rs(min):1.00 , (Refer.)Mass(kg):0.035 , Washer designation Shaft piloted:WS.81112 , h:4.75mm
SL182240 Cylindrical roller bearings

S:9 mm , Basic static load rating (C0):2040 kN , Weight:43.12 Kg , Basic dynamic load rating (C):1420 kN
SF6021 Angular contact ball bearings

D:368.000 mm , d:300.000 mm , C:34.000 mm , B:34.000 mm , Width :34.000mm
AXK5578 Needle roller bearings

Washer designation Housing piloted:GS.81111 , (Refer.)Mass(kg):0.026 , h:5.00mm , rs(min):0.60 , Washer designation Shaft piloted:WS.81111
AST50 26IB16 Plain bearings

ID Chamfer Angle (B deg.):30 , ID Chamfer Length (Ci):0.020 , Material:Carbon steel shell with PTFE / Fiber lining , OD Chamfer Length (Co):0.045
3205ATN9 Angular contact ball bearings

Weight:0.18 Kg , Fatigue load limit (Pu):0.6 , Basic dynamic load rating (C):21.6 kN , Basic static load rating (C0):14.3 kN , Reference speed:12000 r/min
1420 M Self aligning ball bearings

C:70 mm , d:100 mm , B:70 mm , D:265 mm
AST40 1412 Plain bearings

Material:Steel shell with PTFE / Polymer Fiber lining , ID Chamfer Length (Ci):0.300 , ID Chamfer Angle (B deg.):30 , Bearing Length, Nominal (B):12.000 , OD Chamfer Length (Co):0.600 , Bearing Length Tolerance (B tol.) – +0 / -0.30:+0 / 0.30
