100BER29SV1V NSK 100x140x24mm  B 24 mm Angular contact ball bearings

100BER29SV1V NSK 100x140x24mm B 24 mm Angular contact ball bearings

Bearing number100BER29SV1VSize (mm)100x140x24BrandNSKBore Diameter (mm)100Outer Diameter (mm)140Width (mm)24d100 mmD140 mmB24 mmC24 mmAngle (α)25 °a40 mmr min.1.1 mmr1 min.0.6 mmWeight0.902 KgBasic dynamic load rating (C)36 kNBasic static load rating (C0)33.5 kN(Grease) Lubrication Speed10 000 r/min Cross-reference to other manufacturer's…
Contact Us Now !

Product description

100BER29SV1V NSK 100x140x24mm B 24 mm Angular contact ball bearings

Bearing number100BER29SV1V
Size (mm)100x140x24
BrandNSK
Bore Diameter (mm)100
Outer Diameter (mm)140
Width (mm)24
d100 mm
D140 mm
B24 mm
C24 mm
Angle (α)25 °
a40 mm
r min.1.1 mm
r1 min.0.6 mm
Weight0.902 Kg
Basic dynamic load rating (C)36 kN
Basic static load rating (C0)33.5 kN
(Grease) Lubrication Speed10 000 r/min

Cross-reference to other manufacturer’s part number

1204 Self aligning ball bearings

calcUrl:/BearingGuide/html/calculation.jsp , cyl dia:6.35 , CAng:10.892 , KBRG:1352 , r:1
2310-K Self aligning ball bearings

r2 min.:2 mm , r1 min.:2 mm , Weight:1.78 Kg , Basic static load rating (C0):20.1 kN , Basic dynamic load rating (C):65 kN
AR 8 35 53,4 Needle roller bearings

Basic dynamic load rating (C):33.8 kN , Basic static load rating (C0):94 kN , Eb:37.8 mm , Weight:0.052 Kg
SL182956 Cylindrical roller bearings

Bore:11.024 Inch | 280 Millimeter , Weight / LBS:52.008 , Width:2.362 Inch | 60 Millimeter , Outside Diameter:14.961 Inch | 380 Millimeter
3213-2RS Angular contact ball bearings

C:38.1 mm , d:65 mm , Outer Diameter :120mm , B:38.1 mm , D:120 mm , Width :38.1mm
2318K+H2318 Self aligning ball bearings

Basic dynamic load rating (C):153 kN , (Grease) Lubrication Speed:2800 r/min , Weight:8.45 Kg , B1:86 mm , Basic static load rating (C0):57 kN , B2:18 mm
ZA-/HO/62BWKH26D-Y01 Tapered roller bearings

Dw:60 mm , Weight:3 Kg , D:80 mm , T:9.7 mm , Bi:17 mm , ABS:+
YEL 211-200-2F Deep groove ball bearings

Mass complete bearing:1.5 kg , Hexagonal key size for grub screw N:5.556 mm , Recommended tightening torque for grub screw:28.5 N·m , Thread grub screw G2:7/16-20 UNF
3302-B-TVH Angular contact ball bearings

Basic dynamic load rating (C):16.3 kN , Reference speed:12 000 r/min , Basic static load rating (C0):10 kN , Fatigue load limit (Pu):0.46
Z-522934.04.DRGL Spherical roller bearings

B1:431.8 mm , D:980 mm , C:308 mm , B:300 mm
