1205EKTN9 SKF Width  15mm 25x52x15mm  Self aligning ball bearings

1205EKTN9 SKF Width 15mm 25x52x15mm Self aligning ball bearings

Bearing number1205EKTN9Size (mm)25x52x15BrandSKFBore Diameter (mm)25Outer Diameter (mm)52Width (mm)15d25 mmD52 mmB15 mmC15 mmd233.3 mmr1 min.1 mmr2 min.1 mmD145.6 mmda min.30.6 mmDa max.46.4 mmra max.1 mmWeight0.14 KgBasic dynamic load rating (C)14.3 kNBasic static load rating (C0)4 kNFatigue load limit (Pu)0.21Reference speed28000 r/minLimiting sp…
Contact Us Now !

Product description

1205EKTN9 SKF Width 15mm 25x52x15mm Self aligning ball bearings

Bearing number1205EKTN9
Size (mm)25x52x15
BrandSKF
Bore Diameter (mm)25
Outer Diameter (mm)52
Width (mm)15
d25 mm
D52 mm
B15 mm
C15 mm
d233.3 mm
r1 min.1 mm
r2 min.1 mm
D145.6 mm
da min.30.6 mm
Da max.46.4 mm
ra max.1 mm
Weight0.14 Kg
Basic dynamic load rating (C)14.3 kN
Basic static load rating (C0)4 kN
Fatigue load limit (Pu)0.21
Reference speed28000 r/min
Limiting speed18000 r/min
Calculation factor (e)0.28
Calculation factor (kr)0.04
Calculation factor (Y0)2.5
Calculation factor (Y1)2.2

Cross-reference to other manufacturer’s part number

VEB 110 /S 7CE3 Angular contact ball bearings

Weight:0.83 Kg , Basic static load rating (C0):32.5 kN , (Grease) Lubrication Speed:10 300 r/min , Basic dynamic load rating (C):37.7 kN
BLP207-22 Bearing units

Bolt (G):M12 , Basic dynamic load rating (C):25.7 kN , Weight:0.94 Kg , Basic static load rating (C0):15.4 kN , S:8.5 mm
22328A2XK Cylindrical roller bearings

Calculation factor (Y0):1.65 , (Oil) Lubrication Speed:3000 r/min , Calculation factor (e):0.4 , Calculation factor (Y1):1.69 , (Grease) Lubrication Speed:2200 r/min
FYTB 25 TF Bearing units

Bearing:
YAR 205-2F
, Recommended tightening torque for grub screw:4 N·m , Housing:
FYTB 505 M
, End cover:
ECY 205
, Recommended diameter for attachment bolts, mm G:10 mm , Recommended diameter for attachment bolts, inch G:0.375 in
AST11 1420 Plain bearings

ID Chamfer Length (Ci):0.300 , OD Chamfer Length (Co):0.600 , Material:Bronze shell with PTFE / Fiber lining , ID Chamfer Angle (B deg.):30
AST20 WC18 Plain bearings

Housing Counterbore Diameter, Nominal (HD):32.000 , Housing Counterbore Diameter Tolerance (HD tol.):+0.12 / 0 , Material:Carbon steel shell with POM plastic liner , Housing Counterbore Depth Tolerance (Ha tol.) – +0.2 / -0.2:+0.2 / 0.2 , Housing Counterbore Depth (Ha):1.00
ZA-28BWK20A-Y-2CP-01 Tapered roller bearings

b:22.5 mm , Dw:56 mm , ABS:+ , B:66 mm , d2:51 mm , Weight:1.683 Kg
JXR637050 Thrust roller bearings

D:400 mm , Bore Diameter :300mm , Width :37mm , d:300 mm , Outer Diameter :400mm , T:37 mm
RB 30025 Thrust roller bearings

Dp:328 mm , dh:340 mm , Weight:5.9 Kg , Basic dynamic load rating (C):76.3 kN , r min.:3 mm , ds:315 mm
AST650 152116 Plain bearings

ID Chamfer Angle (B deg.):15 , OD Chamfer Length (Co):2.000 , ID Chamfer Length (Ci):1.200 , Material:Cast bronze with solid lubricant inserts.
