1307 NSK 35x80x21mm  e 0.26 Self aligning ball bearings

1307 NSK 35x80x21mm e 0.26 Self aligning ball bearings

Bearing number1307Size (mm)35x80x21BrandNSKBore Diameter (mm)35Outer Diameter (mm)80Width (mm)21d35 mmD80 mmB21 mmC21 mmr min.1.5 mmda min.43 mmDa max.72 mmra max.1.5 mmWeight0.51 KgBasic dynamic load rating (C)25.3 kNBasic static load rating (C0)7.85 kN(Grease) Lubrication Speed7 500 r/min(Oil) Lubrication Speed9 500 r/minCalculation factor (e)0.2…
Contact Us Now !

Product description

1307 NSK 35x80x21mm e 0.26 Self aligning ball bearings

Bearing number 1307
Size (mm) 35x80x21
Brand NSK
Bore Diameter (mm) 35
Outer Diameter (mm) 80
Width (mm) 21
d 35 mm
D 80 mm
B 21 mm
C 21 mm
r min. 1.5 mm
da min. 43 mm
Da max. 72 mm
ra max. 1.5 mm
Weight 0.51 Kg
Basic dynamic load rating (C) 25.3 kN
Basic static load rating (C0) 7.85 kN
(Grease) Lubrication Speed 7 500 r/min
(Oil) Lubrication Speed 9 500 r/min
Calculation factor (e) 0.26
Calculation factor (Y0) 2.6
Calculation factor (Y2) 3.8
SRI 5.42
Y3 2.5
hidYobi 1307
LangID 1
PCD 59
D_ 80
Y2 3.8
SREX 0
cyl count 14
B_ 21
CAD http://service.web2cad.co.jp/pcom/?Maker=NSK_RB&info=nsk_rb/roller_bearings/self_aliging_bb/cylindrical_bore_asmtab.prj&varset={STAN=-}.{ORDER=1307}.{SD=35}.{D=80}.{B=21}.{R=1.5}.{CR1=25300}.{COR1=7850}.{CR2=2580}.{COR2=800}.{LG=7500}.{LO=9500}.{DA1=43.0}.{DA2=72.0}.{RA=1.5}.{E=0.26}.{Y2=3.8}.{Y3=2.50}.{Y0=2.60}.{MASS=0.510}
hidTable ecat_NSSAB
Oil rpm 9500
SRE 0
Y0 2.6
mass 0.51
ra 1.5
GRS rpm 7500
SRIX 0.05
groove inner 48.673
D_a 72
SRIN 0
C0 7.85
groove outer 70.177
SREN 0
X0 1
Prod_Type3 SABB_SA_CB
X1 1
da 43
X2 0.65
e 0.26
yobi 1307
r 1.5
KBRG 1352
CAng 9.714
cyl dia 10.319
calcUrl /BearingGuide/html/calculation.jsp
