1312K NACHI 60x130x31mm  Number of Rows of Balls Double Row Self aligning ball bearings

1312K NACHI 60x130x31mm Number of Rows of Balls Double Row Self aligning ball bearings

Bearing number1312KSize (mm)60x130x31BrandNACHIBore Diameter (mm)60Outer Diameter (mm)130Width (mm)31d60 mmD130 mmB31 mmC31 mmr1 min.2.1 mmda min.71 mmDa max.119 mmra max.2.0 mmWeight1.960 KgBasic dynamic load rating (C)57.2 kNBasic static load rating (C0)20.8 kN(Grease) Lubrication Speed4700 r/min(Oil) Lubrication Speed5700 r/minCalculation factor…
Contact Us Now !

Product description

1312K NACHI 60x130x31mm Number of Rows of Balls Double Row Self aligning ball bearings

Bearing number1312K
Size (mm)60x130x31
BrandNACHI
Bore Diameter (mm)60
Outer Diameter (mm)130
Width (mm)31
d60 mm
D130 mm
B31 mm
C31 mm
r1 min.2.1 mm
da min.71 mm
Da max.119 mm
ra max.2.0 mm
Weight1.960 Kg
Basic dynamic load rating (C)57.2 kN
Basic static load rating (C0)20.8 kN
(Grease) Lubrication Speed4700 r/min
(Oil) Lubrication Speed5700 r/min
Calculation factor (e)0.22
Calculation factor (Y0)3.05
Calculation factor (Y1)2.91
CategorySelf Aligning Ball Bearings
BDI Inventory0.0
Manufacturer NameNACHI
Minimum Buy QuantityN/A
Weight / Kilogram0
Product Group – BDIB00152
Mounting MethodTapered Adapter
EnclosureOpen
Rolling ElementBall Bearing
Adapter SleeveH-312X
Cage MaterialSteel
Precision ClassABEC 1 | ISO P0
Internal ClearanceC0-Medium
Number of Rows of BallsDouble Row
Other FeaturesAllowable Misalignment 3 Deg | 1:12 Taper
Long Description60MM Bore; Tapered Adapter Mount; 130MM Outside Diameter; 31MM Inner Race Width; 31MM Outer Race Width; Open; Steel Cage; Double Row of Balls; ABEC 1 | ISO P0; C0-Medium
Inch – MetricMetric
Category – BDISelf Aligning Ball Bearings
UNSPSC31171532
Harmonized Tariff Code8482.10.50.68
NounBearing
Keyword StringSelf Aligning
Manufacturer URLhttp://www.nachi.com
Weight / LBS4.32106
Outside Diameter5.118 Inch | 130 Millimeter
Bore2.362 Inch | 60 Millimeter
Inner Race Width1.22 Inch | 31 Millimeter
Outer Race Width1.22 Inch | 31 Millimeter
