1316 NACHI 80x170x39mm  Other Features Allowable Misalignment 3 Deg Self aligning ball bearings

1316 NACHI 80x170x39mm Other Features Allowable Misalignment 3 Deg Self aligning ball bearings

Calculation factor (Y0)3.1Calculation factor (Y1)2.9Bearing number1316Size (mm)80x170x39BrandNACHIBore Diameter (mm)80Outer Diameter (mm)170Width (mm)39d80 mmD170 mmB39 mmC39 mmr1 min.2.1 mmda min.92 mmDa max.158 mmra max.2 mmWeight4.18 KgBasic dynamic load rating (C)88.5 kNBasic static load rating (C0)33 kN(Grease) Lubrication Speed3500 r/min(Oil)…
Contact Us Now !

Product description

1316 NACHI 80x170x39mm Other Features Allowable Misalignment 3 Deg Self aligning ball bearings

Calculation factor (Y0) 3.1
Calculation factor (Y1) 2.9
Bearing number 1316
Size (mm) 80x170x39
Brand NACHI
Bore Diameter (mm) 80
Outer Diameter (mm) 170
Width (mm) 39
d 80 mm
D 170 mm
B 39 mm
C 39 mm
r1 min. 2.1 mm
da min. 92 mm
Da max. 158 mm
ra max. 2 mm
Weight 4.18 Kg
Basic dynamic load rating (C) 88.5 kN
Basic static load rating (C0) 33 kN
(Grease) Lubrication Speed 3500 r/min
(Oil) Lubrication Speed 4200 r/min
Calculation factor (e) 0.21
Category Self Aligning Ball Bearings
BDI Inventory 0.0
Manufacturer Name NACHI
Minimum Buy Quantity N/A
Weight / Kilogram 0
Product Group – BDI B00152
Mounting Method Shaft
Enclosure Open
Rolling Element Ball Bearing
Cage Material Steel
Precision Class ABEC 1 | ISO P0
Internal Clearance C0-Medium
Number of Rows of Balls Double Row
Other Features Allowable Misalignment 3 Deg
Long Description 80MM Bore; Shaft Mount; 170MM Outside Diameter; 39MM Inner Race Width; 39MM Outer Race Width; Open; Steel Cage; Double Row of Balls; ABEC 1 | ISO P0; C0-Medium
Inch – Metric Metric
Category – BDI Self Aligning Ball Bearings
UNSPSC 31171532
Harmonized Tariff Code 8482.10.50.68
Noun Bearing
Keyword String Self Aligning
Manufacturer URL http://www.nachi.com
Weight / LBS 9.21531
Outer Race Width 1.535 Inch | 39 Millimeter
Inner Race Width 1.535 Inch | 39 Millimeter
Bore 3.15 Inch | 80 Millimeter
Outside Diameter 6.693 Inch | 170 Millimeter
