1316K NACHI 80x170x39mm  Inner Race Width 1.535 Inch | 39 Millimeter Self aligning ball bearings

1316K NACHI 80x170x39mm Inner Race Width 1.535 Inch | 39 Millimeter Self aligning ball bearings

Bearing number1316KSize (mm)80x170x39BrandNACHIBore Diameter (mm)80Outer Diameter (mm)170Width (mm)39d80 mmD170 mmB39 mmC39 mmr1 min.2.1 mmda min.92 mmDa max.158 mmra max.2 mmWeight4.18 KgBasic dynamic load rating (C)88.5 kNBasic static load rating (C0)33 kN(Grease) Lubrication Speed3500 r/min(Oil) Lubrication Speed4200 r/minCalculation factor (e)0…
Contact Us Now !

Product description

1316K NACHI 80x170x39mm Inner Race Width 1.535 Inch | 39 Millimeter Self aligning ball bearings

Bearing number1316K
Size (mm)80x170x39
BrandNACHI
Bore Diameter (mm)80
Outer Diameter (mm)170
Width (mm)39
d80 mm
D170 mm
B39 mm
C39 mm
r1 min.2.1 mm
da min.92 mm
Da max.158 mm
ra max.2 mm
Weight4.18 Kg
Basic dynamic load rating (C)88.5 kN
Basic static load rating (C0)33 kN
(Grease) Lubrication Speed3500 r/min
(Oil) Lubrication Speed4200 r/min
Calculation factor (e)0.21
Calculation factor (Y0)3.1
Calculation factor (Y1)2.9
CategorySelf Aligning Ball Bearings
BDI Inventory0.0
Manufacturer NameNACHI
Minimum Buy QuantityN/A
Weight / Kilogram0
Product Group – BDIB00152
Mounting MethodTapered Adapter
EnclosureOpen
Rolling ElementBall Bearing
Adapter SleeveH-316X
Cage MaterialSteel
Precision ClassABEC 1 | ISO P0
Internal ClearanceC0-Medium
Number of Rows of BallsDouble Row
Other FeaturesAllowable Misalignment 3 Deg | 1:12 Taper
Long Description80MM Bore; Tapered Adapter Mount; 170MM Outside Diameter; 39MM Inner Race Width; 39MM Outer Race Width; Open; Steel Cage; Double Row of Balls; ABEC 1 | ISO P0; C0-Medium
Inch – MetricMetric
Category – BDISelf Aligning Ball Bearings
UNSPSC31171532
Harmonized Tariff Code8482.10.50.68
NounBearing
Keyword StringSelf Aligning
Manufacturer URLhttp://www.nachi.com
Weight / LBS9.21531
Bore3.15 Inch | 80 Millimeter
Inner Race Width1.535 Inch | 39 Millimeter
Outer Race Width1.535 Inch | 39 Millimeter
Outside Diameter6.693 Inch | 170 Millimeter

Cross-reference to other manufacturer’s part number

TL22240CAKE4 Spherical roller bearings

Calculation factor (e):0.26 , Calculation factor (Y2):3.8 , Calculation factor (Y0):2.5 , (Oil) Lubrication Speed:1 200 r/min
KTSG25-PP-AS Linear bearings

Basic dynamic load rating (C):6.4 kN , H2:30 mm , C2:94 mm , Weight:1.13 Kg
SF3618DB Angular contact ball bearings

C:66.000 mm , Width :66.000mm , D:259.500 mm , B:66.000 mm , d:180.000 mm , Outer Diameter :259.500mm
SL045052-PP Cylindrical roller bearings

Basic dynamic load rating (C):2380 kN , Weight:84.5 Kg , C1:162.2 mm , D1:394 mm , Basic static load rating (C0):4700 kN
16018 Deep groove ball bearings

Outer Diameter :140mm , Width :16mm , D:140 mm , d:90 mm , C:16 mm , B:16 mm
ZARN 3585 TN Complex bearings

Dynamic load rating radial (C):27.5 kN , (Grease) Lubrication Speed:1 250 r/min , Static load rating axial (C0):265 kN , Dynamic load rating axial (C):105 kN , Static load rating radial (C0):53 kN , Weight:1.65 Kg
UKCX08+H2308 Bearing units

B1:46 mm , d:35 mm , A:38 mm , H:120 mm
1680208 Deep groove ball bearings

C:21 mm , Outer Diameter :85mm , Width :39mm , d:40 mm , D:85 mm , B:39 mm
NJ 1017 ML Thrust ball bearings

Fatigue load limit Pu:10.8 kN , Limiting value e:0.2 , Mass bearing:1.08 kg , Calculation factor kr:0.15 , Basic static load rating C0:86.5 kN , Axial load factor Y:0.6
ZKLF2068-2RS Thrust ball bearings

Bolt (G):M6 , Basic static load rating (C0):47 kN , Basic dynamic load rating (C):26 kN , Weight:0.61 Kg
