1318SK NTN Basic static load rating (C0) 44.5 kN 90x190x43mm  Self aligning ball bearings

1318SK NTN Basic static load rating (C0) 44.5 kN 90x190x43mm Self aligning ball bearings

B146 mmrs min3 mmAssociated sleeve referenceH318X e0.22 Y12.8 Y24.3 Y02.9 Radial clearance classCN Precision classP0 Mass5.94 kgDynamic load, C117 kNStatic load, C044.5 kNNlim (oil)3.800 rpmNlim (grease)3.200 rpmMin operating temperature, Tmin-20 °CMax operating temperature, Tmax120 °Cda min103 mmda max116 mmdb min96 mmCe min6 mmDa max177 mmra ma…
Contact Us Now !

Product description

1318SK NTN Basic static load rating (C0) 44.5 kN 90x190x43mm Self aligning ball bearings

B146 mm
rs min3 mm
Associated sleeve referenceH318X
e0.22
Y12.8
Y24.3
Y02.9
Radial clearance classCN
Precision classP0
Mass5.94 kg
Dynamic load, C117 kN
Static load, C044.5 kN
Nlim (oil)3.800 rpm
Nlim (grease)3.200 rpm
Min operating temperature, Tmin-20 °C
Max operating temperature, Tmax120 °C
da min103 mm
da max116 mm
db min96 mm
Ce min6 mm
Da max177 mm
ra max2.5 mm
Bearing number1318SK
Size (mm)90x190x43
BrandNTN
Bore Diameter (mm)90
Outer Diameter (mm)190
Width (mm)43
d90 mm
D190 mm
B43 mm
C43 mm
r min.3 mm
da min.103 mm
Da max.177 mm
ra max.2.5 mm
Weight5.94 Kg
Basic dynamic load rating (C)117 kN
Basic static load rating (C0)44.5 kN
(Grease) Lubrication Speed3 200 r/min
(Oil) Lubrication Speed3 800 r/min
Calculation factor (e)0.22
Calculation factor (Y0)2.9
Calculation factor (Y1)2.8
