13685/13620 KOYO Calculation factor (Y0) 0.82  Tapered roller bearings

13685/13620 KOYO Calculation factor (Y0) 0.82 Tapered roller bearings

Bearing number13685/13620BrandKOYOBore Diameter (mm)38.1Width (mm)19.05d38.1 mmT19.05 mmB19.05 mmC15.083 mma16.1 mmr min.3.6 mmr1 min.0.8 mmDa62 mmdb43 mmda49.5 mmDb65 mmBasic dynamic load rating (C)49.2 kNBasic static load rating (C0)62 kNCalculation factor (e)0.4Calculation factor (Y0)0.82 Cross-reference to other manufacturer's part number AST50…
Contact Us Now !

Product description

13685/13620 KOYO Calculation factor (Y0) 0.82 Tapered roller bearings

Bearing number13685/13620
BrandKOYO
Bore Diameter (mm)38.1
Width (mm)19.05
d38.1 mm
T19.05 mm
B19.05 mm
C15.083 mm
a16.1 mm
r min.3.6 mm
r1 min.0.8 mm
Da62 mm
db43 mm
da49.5 mm
Db65 mm
Basic dynamic load rating (C)49.2 kN
Basic static load rating (C0)62 kN
Calculation factor (e)0.4
Calculation factor (Y0)0.82

Cross-reference to other manufacturer’s part number

AST50 76IB76 Plain bearings

Material:Carbon steel shell with PTFE / Fiber lining , ID Chamfer Length (Ci):0.031 , Bearing Length Tolerance (B tol.) – +.010 / -0.010:+.010 / 0.010 , OD Chamfer Length (Co):0.072 , ID Chamfer Angle (B deg.):30
20206 Spherical roller bearings

B:16 mm , D:62 mm , C:16 mm , d:30 mm
CRBS 508 V UU Thrust roller bearings

da:54 mm , r min.:0.4 mm , Da:61 mm , Basic dynamic load rating (C):6.93 kN , Weight:0.084 Kg
22314AEXK Cylindrical roller bearings

Calculation factor (Y0):1.67 , Calculation factor (e):0.4 , Basic static load rating (C0):365 kN , (Oil) Lubrication Speed:6000 r/min , (Grease) Lubrication Speed:4650 r/min , Calculation factor (Y1):1.71
QT7 Tapered roller bearings

r min.:2.5 mm , Basic static load rating (C0):218 kN , Basic dynamic load rating (C):192 kN , r1 min.:3 mm , Weight:3 Kg
AX 4,5 120 155 Needle roller bearings

Basic static load rating (C0):590 kN , Basic dynamic load rating (C):80 kN , Ea:147.3 mm , Weight:0.182 Kg , Eb:124.2 mm
UKP312 Bearing units

(Refer.)Unit mass(kg):R1/8 , f0:13.2 , S:9.4 , B:62
NP636046/NP801481 Tapered roller bearings

T:23.368 mm , B:23.114 mm , Width :23.368mm , d:25.4 mm , D:59.53 mm
29268 M Thrust roller bearings

(Grease) Lubrication Speed:995 r/min , Weight:33 Kg , Basic dynamic load rating (C):1107 kN , E:36 mm , Basic static load rating (C0):5292 kN
180RN92 Cylindrical roller bearings

E:294 mm , D:320 mm , B:108 mm , r max:3 mm , C:108 mm
