21310RHK KOYO Weight 1.35 Kg 50x110x27mm Spherical roller bearings

Bearing number21310RHKSize (mm)50x110x27BrandKOYOBore Diameter (mm)50Outer Diameter (mm)110Width (mm)27d50 mmD110 mmB27 mmC27 mmr min.2 mmda min.60 mmDa max.100 mmra max.2 mmWeight1.35 KgBasic dynamic load rating (C)128 kNBasic static load rating (C0)151 kN(Grease) Lubrication Speed3300 r/min(Oil) Lubrication Speed4400 r/minCalculation factor (e)0.…

Product description

21310RHK KOYO Weight 1.35 Kg 50x110x27mm Spherical roller bearings

Bearing number	21310RHK
Size (mm)	50x110x27
Brand	KOYO
Bore Diameter (mm)	50
Outer Diameter (mm)	110
Width (mm)	27
d	50 mm
D	110 mm
B	27 mm
C	27 mm
r min.	2 mm
da min.	60 mm
Da max.	100 mm
ra max.	2 mm
Weight	1.35 Kg
Basic dynamic load rating (C)	128 kN
Basic static load rating (C0)	151 kN
(Grease) Lubrication Speed	3300 r/min
(Oil) Lubrication Speed	4400 r/min
Calculation factor (e)	0.25
Calculation factor (Y0)	2.65
Calculation factor (Y1)	2.71

Cross-reference to other manufacturer’s part number

23222EMW33 Thrust roller bearings	Width :69.800mm , d:110.000 mm , D:200.000 mm , H:69.800 mm
25BGR10H Angular contact ball bearings	Basic dynamic load rating (C):7.9 kN , (Oil) Lubrication Speed:77 800 r/min , (Grease) Lubrication Speed:52 800 r/min , Basic static load rating (C0):3.75 kN
3308 ZZ Angular contact ball bearings	Weight:0.95 Kg , Basic static load rating (C0):43 kN , Basic dynamic load rating (C):56.2 kN , (Grease) Lubrication Speed:5000 r/min
2212-2RS Self aligning ball bearings	Weight:1.13 Kg , C:28 mm , Basic dynamic load rating (C):48.8 kN , Basic static load rating (C0):17 kN
1302 Self aligning ball bearings	Bore:0.591 Inch \| 15 Millimeter , Inner Race Width:0.512 Inch \| 13 Millimeter , Outside Diameter:1.654 Inch \| 42 Millimeter , Outer Race Width:0.512 Inch \| 13 Millimeter
T1115 Thrust roller bearings	Basic dynamic load rating (Ca90):1090000 , R:6.4 mm , r:6.4 mm , Basic static load rating (C0):14000000 kN , Weight:125 Kg , T:133.35 mm
USPG211 Bearing units	L:140 mm , Weight:3.4 Kg , Basic dynamic load rating (C):43.55 kN , Thread (G):M6x1 , L1:40 mm , Thread (N1):M16
T301W Thrust roller bearings	D:133.35 mm , Width :33.338mm , T:33.338 mm , R:2.3 mm , d:76.454 mm
ZARN75155-TV Complex bearings	EAN:4012802418842 , Product Group – BDI:B00234 , Minimum Buy Quantity:N/A , Weight / Kilogram:9.46
2LA-HSE004CG/GNP42 Angular contact ball bearings	D:42 mm , Width :12mm , d:20 mm , Angle (α):15 ° , B:12 mm , C:12 mm
