Home > Spherical roller bearings > 21317 E SKF 180x85x41mm Width 1.614 Inch | 41 Millimeter Spherical roller bearings
21317 E SKF 180x85x41mm  Width 1.614 Inch | 41 Millimeter Spherical roller bearings

21317 E SKF 180x85x41mm Width 1.614 Inch | 41 Millimeter Spherical roller bearings

Bearing number21317 ESize (mm)180x85x41BrandSKFBore Diameter (mm)180Outer Diameter (mm)85Width (mm)41d85 mmD180 mmB41 mmd2106 mmD1141 mmb6 mmK3 mmr1,2 - min.3 mmda - min.99 mmDa - max.166 mmra - max.2.5 mmBasic dynamic load rating - C331 kNBasic static load rating - C0375 kNFatigue load limit - Pu39 kNReference speed3800 r/minLimiting speed5300 r/m…
Contact Us Now !

Product description

21317 E SKF 180x85x41mm Width 1.614 Inch | 41 Millimeter Spherical roller bearings

Bearing number21317 E
Size (mm)180x85x41
BrandSKF
Bore Diameter (mm)180
Outer Diameter (mm)85
Width (mm)41
d85 mm
D180 mm
B41 mm
d2106 mm
D1141 mm
b6 mm
K3 mm
r1,2 – min.3 mm
da – min.99 mm
Da – max.166 mm
ra – max.2.5 mm
Basic dynamic load rating – C331 kN
Basic static load rating – C0375 kN
Fatigue load limit – Pu39 kN
Reference speed3800 r/min
Limiting speed5300 r/min
Calculation factor – e0.24
Calculation factor – Y12.8
Calculation factor – Y24.2
Calculation factor – Y02.8
CategorySpherical Roller Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram5.4
EAN7316577742308
Product Group – BDIB04311
Internal ClearanceC0-Medium
Mounting MethodShaft Mount
Rolling ElementSpherical Roller Bearing
Bore ProfileStraight
Cage MaterialSteel
EnclosureOpen
Number of Rows of RollersDouble Row
RelubricatableYes
Withdrawal SleeveNot Applicable
Withdrawal NutNot Applicable
Inch – MetricMetric
Long Description85MM Straight Bore; 180MM Outside Diameter; 41MM Width; C0-Medium Clearance; Shaft Mount; Double Row of Spherical Roller Bearings; Steel Cage Material; Open Enclosure; Relubricatable
Category – BDISpherical Roller Bearing
UNSPSC31171510
Harmonized Tariff Code84823080
NounBearing
Keyword StringSpherical
Manufacturer URLhttp://www.skf.com
Weight / LBS11.894
Outside Diameter7.087 Inch | 180 Millimeter
Width1.614 Inch | 41 Millimeter
Bore3.346 Inch | 85 Millimeter
Adapter Part NumberNot Applicable Inch | Not Applicable Millimeter
bore diameter:85 mm
maximum rpm:5300 RPM
outside diameter:180 mm
operating temperature range:Maximum of +390 °F
overall width:4.3800 in
cage material:Steel
bore type:Straight
bearing material:Steel
outer ring type:Not Split
precision rating:Not Rated
internal clearance:C0
finish/coating:Uncoated
closure type:Open
outer ring width:41 mm
lubrication hole type:Lubrication Groove & Hole
fillet radius:2.5 mm
dynamic load capacity:325 kN
series:213
static load capacity:375 kN
d2106 mm
D1141 mm
r1,2 min.3 mm
da min.99 mm
Da max.166 mm
ra max.2.5 mm
Basic dynamic load rating C331 kN
Basic static load rating C0375 kN
Fatigue load limit Pu39 kN
Calculation factor e0.24
Calculation factor Y12.8
Calculation factor Y24.2
Calculation factor Y02.8
Mass bearing5.2 kg

Cross-reference to other manufacturer’s part number

2319 Self aligning ball bearings

(Oil) Lubrication Speed:3200 r/min , Calculation factor (Y0):1.8 , Calculation factor (Y1):1.7 , Calculation factor (e):0.37
1213 K Self aligning ball bearings

Calculation factor (Y2):5.7 , Calculation factor (Y0):3.8 , (Oil) Lubrication Speed:6 000 r/min , Calculation factor (e):0.17 , (Grease) Lubrication Speed:4 800 r/min , Basic static load rating (C0):12.5 kN
24148MBK30W33 Spherical roller bearings

Max Speed (Grease) (X000 RPM):1 , Material:52100 Chrome steel. or equivalent , Weight (g):78.430.00 , Max Speed (Oil) (X000 RPM):1
ER3.40.3550.400-1SPPN Thrust roller bearings

Hi:170 mm , Fi:3390 mm , Ht:220 mm , He:210 mm
TP1024-1 Needle roller bearings

Weight:0.0035 Kg , Eb:21.8 mm , Basic static load rating (C0):18.3 kN , Ea:15.2 mm , Basic dynamic load rating (C):6.35 kN
201KDG Deep groove ball bearings

D:32 mm , Basic dynamic load rating (C):7.6 kN , C:10 mm , B:10 mm , Weight:0.036 Kg
SEA140 /NS 7CE3 Angular contact ball bearings

Basic static load rating (C0):58.5 kN , (Grease) Lubrication Speed:7 000 r/min , (Oil) Lubrication Speed:11 000 r/min , Basic dynamic load rating (C):42.3 kN , Fatigue load limit (Pu):2
LMEKM40 Linear bearings

â„“:70.5 Tolerance h14 , Weight:1.56 Kg , Basic dynamic load rating (C):3.43 kN , Tolerance perpendicularity (C):20
USFE207 Bearing units

N:14 mm , Basic dynamic load rating (C):25.7 kN , Thread (G):R1/8" , Weight:1.5 Kg , L:118 mm , A2:44.5 mm
13MKM1912 Needle roller bearings

b:9.3 mm , Basic static load rating (C0):6.7 kN , C:12 mm , Basic dynamic load rating (C):5.85 kN , Weight:0.011 Kg
