2203G15 SNR 17x40x16mm  Characteristic cage frequency, FTF 0.38 Hz Self aligning ball bearings

2203G15 SNR 17x40x16mm Characteristic cage frequency, FTF 0.38 Hz Self aligning ball bearings

d123.9 mmD133.9 mmrs min0.6 mme0.46 Y11.37 Y22.12 Y01.43 Radial clearance classCN Precision classP0 Mass0.09 kgDynamic load, C11.5 kNStatic load, C02.75 kNNref18.000 rpmNlim23.000 rpmMin operating temperature, Tmin-20 °CMax operating temperature, Tmax120 °CCharacteristic cage frequency, FTF0.38 HzCharacteristic rolling element frequency, BSF3.87 …
Contact Us Now !

Product description

2203G15 SNR 17x40x16mm Characteristic cage frequency, FTF 0.38 Hz Self aligning ball bearings

d123.9 mm
D133.9 mm
rs min0.6 mm
e0.46
Y11.37
Y22.12
Y01.43
Radial clearance classCN
Precision classP0
Mass0.09 kg
Dynamic load, C11.5 kN
Static load, C02.75 kN
Nref18.000 rpm
Nlim23.000 rpm
Min operating temperature, Tmin-20 °C
Max operating temperature, Tmax120 °C
Characteristic cage frequency, FTF0.38 Hz
Characteristic rolling element frequency, BSF3.87 Hz
Characteristic outer ring frequency, BPF03.83 Hz
Characteristic inner ring frequency, BPFI6.17 Hz
da min21 mm
Da max36 mm
ra max0.6 mm
Bearing number2203G15
Size (mm)17x40x16
BrandSNR
Bore Diameter (mm)17.000
Outer Diameter (mm)40.000
Width (mm)16.000
d17.000 mm
D40.000 mm
B16.000 mm
C16.000 mm

Cross-reference to other manufacturer’s part number

230/600E Cylindrical roller bearings

(Oil) Lubrication Speed:600 r/min , Calculation factor (Y0):3.03 , Calculation factor (e):0.22 , (Grease) Lubrication Speed:480 r/min , Calculation factor (Y1):3.1
YET206-102 Deep groove ball bearings

Weight:0.32 Kg , Fatigue load limit (Pu):0.475 , s1:26.7 mm , Basic static load rating (C0):11.2 kN , Basic dynamic load rating (C):19.5 kN
2LA-BNS913LLBG/GNP42 Angular contact ball bearings

B:13 mm , Angle (α):20 ° , D:90 mm , C:13 mm
UKP328H Bearing units

N1:55 mm , L1:140 mm , Weight:96.3 Kg , Thread (G):M10x1 , Basic dynamic load rating (C):275 kN , N:40 mm
3308 Angular contact ball bearings

(Grease) Lubrication Speed:4600 r/min , Weight:1.07 Kg , Basic static load rating (C0):53.8 kN , Basic dynamic load rating (C):54.1 kN
22328A2XK Cylindrical roller bearings

(Oil) Lubrication Speed:3000 r/min , Calculation factor (Y1):1.69 , Calculation factor (e):0.4 , Calculation factor (Y0):1.65
TLA 48 Z Needle roller bearings

C:8 mm , Basic dynamic load rating (C):0.00135 kN , Fw:4 mm , Weight:0.00154 Kg , Basic static load rating (C0):0.00101 kN , D:8 mm
NKIB 5906 Complex bearings

Dynamic load rating radial (C):23.75 kN , Static load rating axial (C0):6.935 kN , Static load rating radial (C0):33.7 kN , Dynamic load rating axial (C):4.513 kN
25BTM3119A Needle roller bearings

(Grease) Lubrication Speed:8500 r/min , Basic dynamic load rating (C):16.3 kN , Basic static load rating (C0):30.1 kN , Weight:0.026 Kg , C:19 mm
T113 Thrust roller bearings

D:55.562 mm , Outer Diameter :55.562mm , T:15.875 mm , Width :15.875mm , R:0.8 mm , d:28.829 mm
