Home > Spherical roller bearings > 24122-E1-2VSR-H40 FAG 110x180x69mm Calculation factor (Y1) 1.96 Spherical roller bearings
24122-E1-2VSR-H40 FAG 110x180x69mm  Calculation factor (Y1) 1.96 Spherical roller bearings

24122-E1-2VSR-H40 FAG 110x180x69mm Calculation factor (Y1) 1.96 Spherical roller bearings

Outer Diameter (mm)180Bearing number24122-E1-2VSR-H40Size (mm)110x180x69BrandFAGBore Diameter (mm)110Width (mm)69d110 mmD180 mmB69 mmC69 mmd2120.8 mmr min.2 mmD1167.1 mmda min.120.8 mmDa max.169 mmra max.2 mmWeight6.8 KgBasic dynamic load rating (C)530 kNBasic static load rating (C0)750 kNFatigue load limit (Pu)84Limiting speed840 r/minCalculation …
Contact Us Now !

Product description

24122-E1-2VSR-H40 FAG 110x180x69mm Calculation factor (Y1) 1.96 Spherical roller bearings

Outer Diameter (mm)180
Bearing number24122-E1-2VSR-H40
Size (mm)110x180x69
BrandFAG
Bore Diameter (mm)110
Width (mm)69
d110 mm
D180 mm
B69 mm
C69 mm
d2120.8 mm
r min.2 mm
D1167.1 mm
da min.120.8 mm
Da max.169 mm
ra max.2 mm
Weight6.8 Kg
Basic dynamic load rating (C)530 kN
Basic static load rating (C0)750 kN
Fatigue load limit (Pu)84
Limiting speed840 r/min
Calculation factor (e)0.34
Calculation factor (Y0)1.92
Calculation factor (Y1)1.96

Cross-reference to other manufacturer’s part number

TA 1212 Z Needle roller bearings

Weight:0.0105 Kg , C:12 mm , Basic dynamic load rating (C):6 kN , Basic static load rating (C0):6.31 kN
2216 K Self aligning ball bearings

Calculation factor (e):0.25 , Calculation factor (Y0):2.7 , (Oil) Lubrication Speed:5 000 r/min , Calculation factor (Y2):3.9
TAF 253320 Needle roller bearings

Weight:0.042 Kg , Basic static load rating (C0):32.1 kN , Basic dynamic load rating (C):20 kN , r min.:0.3 mm , Da max.:31 mm
24128EX1 Cylindrical roller bearings

Calculation factor (e):0.36 , Basic static load rating (C0):1180 kN , (Grease) Lubrication Speed:2100 r/min , Calculation factor (Y0):1.83 , (Oil) Lubrication Speed:2800 r/min , Calculation factor (Y1):1.87
ALP202 Bearing units

Basic static load rating (C0):4.8 kN , Basic dynamic load rating (C):9.55 kN , Weight:0.39 Kg , Bolt (G):M10
TAPR 705 DO Plain bearings

Weight:1.25 Kg , Basic dynamic load rating (C):62 kN , Angle:6 ° , Bolt (G):M10x20 , d5:77 r/min
ASR7-1A Spherical roller bearings

W:16.764 mm , H:0.136 mm , B:15.875 mm , A:3.512 mm , P:351 mm
SL182988 Cylindrical roller bearings

C:95 mm , B:95 mm , D:600 mm , d:440 mm
ZKLFA1050-2Z Angular contact ball bearings

da max:27 mm , Static load rating axial (C0):18.8 kN , da min.:14 mm , Dynamic load rating axial (C):13.4 kN , Weight:0.18 Kg
X32211M/Y32211M Tapered roller bearings

R:2 mm , B:25 mm , r:1.5 mm , C:21 mm
