24144-B-K30 FAG ra max. 3 mm 220x370x150mm  Spherical roller bearings

24144-B-K30 FAG ra max. 3 mm 220x370x150mm Spherical roller bearings

Bearing number24144-B-K30Size (mm)220x370x150BrandFAGBore Diameter (mm)220Outer Diameter (mm)370Width (mm)150d220 mmD370 mmB150 mmC150 mmn12.2 mmr min.4 mmD1311.7 mmda min.237 mmDa max.353 mmra max.3 mmd56.3 r/minWeight64.4 KgBasic dynamic load rating (C)1900 kNBasic static load rating (C0)3450 kNFatigue load limit (Pu)197Reference speed720 r/minLi…
Contact Us Now !

Product description

24144-B-K30 FAG ra max. 3 mm 220x370x150mm Spherical roller bearings

Bearing number24144-B-K30
Size (mm)220x370x150
BrandFAG
Bore Diameter (mm)220
Outer Diameter (mm)370
Width (mm)150
d220 mm
D370 mm
B150 mm
C150 mm
n12.2 mm
r min.4 mm
D1311.7 mm
da min.237 mm
Da max.353 mm
ra max.3 mm
d56.3 r/min
Weight64.4 Kg
Basic dynamic load rating (C)1900 kN
Basic static load rating (C0)3450 kN
Fatigue load limit (Pu)197
Reference speed720 r/min
Limiting speed1 300 r/min
Calculation factor (e)0.41
Calculation factor (Y0)1.6
Calculation factor (Y1)1.63

Cross-reference to other manufacturer’s part number

1206K Self aligning ball bearings

Outside Diameter:2.441 Inch | 62 Millimeter , Outer Race Width:0.63 Inch | 16 Millimeter , Inner Race Width:0.63 Inch | 16 Millimeter , Bore:1.181 Inch | 30 Millimeter
22219 Spherical roller bearings

(Grease) Lubrication Speed:3672 r/min , Basic static load rating (C0):441 kN , Weight:4.15 Kg , Basic dynamic load rating (C):372 kN , K:4.5 mm
29268 M Thrust roller bearings

Basic dynamic load rating (C):1150 kN , Basic static load rating (C0):5300 kN , Weight:33.6 Kg , C:37 mm
22315EG15KW33 Thrust roller bearings

D:160.000 mm , H:55.000 mm , Width :55.000mm , d:75.000 mm , Outer Diameter :160.000mm
140RJ51 Cylindrical roller bearings

r max:2 mm , E:206 mm , F:155 mm , B:36 mm , D:220 mm , C:36 mm
LM80UU Linear bearings

W:4.15 mm , Basic dynamic load rating (C):10.13 kN , L:140 mm , Weight:4.1 Kg , D1:116 mm
XLT5 Thrust ball bearings

Weight:1.67 Kg , Basic dynamic load rating (C):67 kN , Basic static load rating (C0):228 kN , (Grease) Lubrication Speed:1100 r/min , D1:128.5875 mm
SQY6-RS Plain bearings

Angle:25 ° , L1:30.5 mm , S2:11 mm , Thread (G) – 1/4-28:1/428 , Weight:0.039 Kg
YRT 200 Thrust roller bearings

Static load rating axial (C0):765 kN , Dynamic load rating radial (C):81.5 kN , Static load rating radial (C0):220 kN , Dynamic load rating axial (C):120 kN
AST650 11013080 Plain bearings

OD Chamfer Length (Co):3.000 , ID Chamfer Length (Ci):1.200 , Material:Cast bronze with solid lubricant inserts. , ID Chamfer Angle (B deg.):15
