24148-B-K30+AH24148 FAG 240x400x160mm  Weight 91.1 Kg Spherical roller bearings

24148-B-K30+AH24148 FAG 240x400x160mm Weight 91.1 Kg Spherical roller bearings

Bearing number24148-B-K30+AH24148Size (mm)240x400x160BrandFAGBore Diameter (mm)240Outer Diameter (mm)400Width (mm)160d240 mmd1220 mmD400 mmB160 mmC160 mmn12.2 mmI180 mma15 mmb20 mmr min.4 mmD1338 mmThread (G)Tr260X4da min.257 mmDa max.383 mmra max.3 mmd56.3 r/minWeight91.1 KgBasic dynamic load rating (C)2120 kNBasic static load rating (C0)3900 kNFa…
Contact Us Now !

Product description

24148-B-K30+AH24148 FAG 240x400x160mm Weight 91.1 Kg Spherical roller bearings

Bearing number24148-B-K30+AH24148
Size (mm)240x400x160
BrandFAG
Bore Diameter (mm)240
Outer Diameter (mm)400
Width (mm)160
d240 mm
d1220 mm
D400 mm
B160 mm
C160 mm
n12.2 mm
I180 mm
a15 mm
b20 mm
r min.4 mm
D1338 mm
Thread (G)Tr260X4
da min.257 mm
Da max.383 mm
ra max.3 mm
d56.3 r/min
Weight91.1 Kg
Basic dynamic load rating (C)2120 kN
Basic static load rating (C0)3900 kN
Fatigue load limit (Pu)231
Reference speed660 r/min
Limiting speed1 200 r/min
Calculation factor (e)0.41
Calculation factor (Y0)1.62
Calculation factor (Y1)1.66
