Home > Spherical roller bearings > 241/900ECAK30F/W33 SKF 900x1420x515mm ra max. 10 mm Spherical roller bearings
241/900ECAK30F/W33 SKF 900x1420x515mm  ra max. 10 mm Spherical roller bearings

241/900ECAK30F/W33 SKF 900x1420x515mm ra max. 10 mm Spherical roller bearings

Bearing number241/900ECAK30F/W33Size (mm)900x1420x515BrandSKFBore Diameter (mm)900Outer Diameter (mm)1420Width (mm)515d900 mmD1420 mmB515 mmC515 mmb22.3 mmd21043 mmr1 min.12 mmr2 min.12 mmD11235 mmK12 mmda min.948 mmDa max.1372 mmra max.10 mmWeight3350 KgBasic dynamic load rating (C)24500 kNBasic static load rating (C0)49000 kNFatigue load limit (P…
Contact Us Now !

Product description

241/900ECAK30F/W33 SKF 900x1420x515mm ra max. 10 mm Spherical roller bearings

Bearing number241/900ECAK30F/W33
Size (mm)900x1420x515
BrandSKF
Bore Diameter (mm)900
Outer Diameter (mm)1420
Width (mm)515
d900 mm
D1420 mm
B515 mm
C515 mm
b22.3 mm
d21043 mm
r1 min.12 mm
r2 min.12 mm
D11235 mm
K12 mm
da min.948 mm
Da max.1372 mm
ra max.10 mm
Weight3350 Kg
Basic dynamic load rating (C)24500 kN
Basic static load rating (C0)49000 kN
Fatigue load limit (Pu)2700
Reference speed120 r/min
Limiting speed180 r/min
Calculation factor (e)0.35
Calculation factor (Y0)1.8
Calculation factor (Y1)1.9

Cross-reference to other manufacturer’s part number

120RN03 Cylindrical roller bearings

r max:2.5 mm , B:55 mm , C:55 mm , E:235 mm
712047610 Complex bearings

D:21 mm , D1:35 mm , d:15 mm , C:18.1 mm
23122EMKW33 Thrust roller bearings

Width :56.000mm , d:110.000 mm , H:56.000 mm , D:180.000 mm
W 61907 R-2Z Deep groove ball bearings

Calculation factor kr:0.025 , Limiting speed:13000 r/min , Calculation factor f0:15.7 , Fatigue load limit Pu:0.325 kN
11205ETN9 Self aligning ball bearings

Calculation factor (kr):0.04 , Calculation factor (Y1):2.2 , Calculation factor (e):0.28 , Calculation factor (Y0):2.5
20V2825B Needle roller bearings

Basic static load rating (C0):35.4 kN , Weight:0.037 Kg , Ew:28 mm , B:25 mm , Basic dynamic load rating (C):28.8 kN
TSM 16.1 Plain bearings

Angle:15 ° , Basic dynamic load rating (C):21 kN , Weight:0.18 Kg , C1:15 mm , Thread (G):M16x1.5
K81115TN Thrust roller bearings

D:100 mm , d:75 mm , Basic static load rating (C0):339.6 kN , Basic dynamic load rating (C):104.5 kN , Dw:7.5 mm , Weight:0.096 Kg
1312 Self aligning ball bearings

B:31 mm , D:130 mm , C:31 mm , d:60 mm
T188 Thrust roller bearings

Width :23.812mm , d:47.879 mm , R:0.8 mm , T:23.812 mm , D:82.956 mm
