250MCM14-1B Series Axial Piston Motor

250MCM14-1B Series Axial Piston Motor

Our mission is to serve our customers as a trusted ally, providing you with the loyalty of a business partner and the economics of an outside vendor. Since many vacuum processes are critical steps in applications, we vow to make sure that our customers have what they need to run their vacuum equipment and processes with maximum efficiency and relia…
Contact Us Now !

Product description

250MCM14-1B Series Axial Piston Motor

Our mission is to serve our customers as a trusted ally, providing you with the loyalty of a business partner and the economics of an outside vendor. Since many vacuum processes are critical steps in applications, we vow to make sure that our customers have what they need to run their vacuum equipment and processes with maximum efficiency and reliability. We will be there when you need us.if you’re looking for Hydraulic Pumps,Pumps,Hydraulic Motors,Motors,Hydraulic Cylinder,Air Cylinders,Solenoid Valves,Pressure Valves,Check Valves, Flow Valves, Proportional Valves, Filter Elements,Fittings,Gas Claw,Vacuum,Connectors,Components and Accessories,Auto spare parts, then you’ve come to the right place., enable Leader to greatly enhance quality deeply and broadly, and continue towards the top goal; with rigorous and far-reaching quality strategy and perseverance

MCM14-1B Series Axial Piston Motor

250MCM14-1B Series Axial Piston Motor



Quantitative swashplate axial piston motor MCM14-1B Features

Quantitative swashplate axial piston motor MCM14-1B is using oil distribution plate of oil distribution, block rotating axial plunger pump. Quantitative swashplate axial piston motor MCM14-1B due to sliding boots and variable between head, oil distribution plate and cylinder adopts the hydraulic structure of static equilibrium, and compared with other types of plunger pump, quantitative swashplate axial piston motor MCM14-1B has a simple structure, small volume, high efficiency, long life, light weight, strong self-priming capacity, etc.

Quantitative swashplate axial piston pump/motor MCM14-1B is suitable for the machine tool machine, suitable for forging machinery, applicable to the metallurgical machinery, is suitable for engineering machinery, suitable for mining machinery, is suitable for wind power machinery and other hydraulic transmission system. Quantitative inclined.

Quantitative swashplate axial piston motor MCM14-1B Use notice:

Quantitative swashplate axial piston motor MCM14-1B pump rotate to, according to clockwise rotate to () from the view of shaft end users need to counter clockwise rotate to or do motor, must when ordering.
Quantitative swashplate axial piston motor MCM14-1B and with elastic coupling between motor, and requires concentric, otherwise it will produce noise, lower efficiency and other failures.

Quantitative swashplate axial piston pump/motor MCM14-1B self-priming ability to a certain extent, can be installed in the fuel tank used above, height is not more than 0.5 M. But for the flow rate is greater than 160 l/min recommends to flow backward self-priming pump.

Quantitative swashplate axial piston pump/motor MCM14-1B in the first start, must through drainage hole to the pump housing

MCM14-1B Series Axial Piston Motor Drawing
250MCM14-1B Series Axial Piston Motor



MCM14-1B Series Axial Piston Motor Specification:


Model No#

Pressure

MPA

Displacement

ML/R

Flow

L/MIN

Maximum transmission power


KW

Theoretical maximum torque


NM

Weight

KG

1000R/MIN 1500R/MIN 1000R/MIN 1500R/MIN
1.25MCM14-1B 31.5 1.25 1.25 1.88 0.7 1.1 6.3 6.9
2.5MCM14-1B 31.5 2.5 2.5 3.75 1.43 2.2 12.6 7.2
10MCM14-1B 31.5 10 10 15 6.2 9.3 56 16.4~26
13MCM14-1B 31.5 13 13 19.5 8 12 72 16.4~26
16MCM14-1B 31.5 16 16 24 9.9 14.8 89 16.4~26
25MCM14-1B 31.5 25 25 37.5 14.6 22 139 28.4~41
32MCM14-1B 31.5 32 32 48 18.7 28 178 28.4~41
40MCM14-1B 31.5 40 40 60 23.3 35 223 28.4~41
63MCM14-1B 31.5 63 63 94.5 36.8 55 352 56~74
80MCM14-1B 31.5 80 80 120 46.7 70 445 56~74
100MCM14-1B 31.5 100 100 150 58 87.5 557 80~110
125MCM14-1B 31.5 125 125 188 73 109 696 80~110
160MCM14-1B 31.5 160 160 240 93 140 891 138~168
250MCM14-1B 31.5 250 250 375 146 218 1392 200~232
400MCM14-1B 31.5 400 400   233   2228 200~232
