25BER19S NSK 25x42x9mm  r1 min. 0.15 mm Angular contact ball bearings

25BER19S NSK 25x42x9mm r1 min. 0.15 mm Angular contact ball bearings

Bearing number25BER19SSize (mm)25x42x9BrandNSKBore Diameter (mm)25Outer Diameter (mm)42Width (mm)9d25 mmD42 mmB9 mmC9 mmAngle (α)25 °a12.3 mmb0.5 mmr min.0.3 mmr1 min.0.15 mmA31 mmda min.27.5 mmDa max.39.5 mmra max.0.3 mmWeight0.042 KgBasic dynamic load rating (C)5.7 kNBasic static load rating (C0)3.4 kN(Grease) Lubrication Speed35900 r/m…
Contact Us Now !

Product description

25BER19S NSK 25x42x9mm r1 min. 0.15 mm Angular contact ball bearings

Bearing number25BER19S
Size (mm)25x42x9
BrandNSK
Bore Diameter (mm)25
Outer Diameter (mm)42
Width (mm)9
d25 mm
D42 mm
B9 mm
C9 mm
Angle (α)25 °
a12.3 mm
b0.5 mm
r min.0.3 mm
r1 min.0.15 mm
A31 mm
da min.27.5 mm
Da max.39.5 mm
ra max.0.3 mm
Weight0.042 Kg
Basic dynamic load rating (C)5.7 kN
Basic static load rating (C0)3.4 kN
(Grease) Lubrication Speed35900 r/min
