3006-B-TVH FAG 30x55x19mm  m 0.16 kg / Weight Angular contact ball bearings

3006-B-TVH FAG 30x55x19mm m 0.16 kg / Weight Angular contact ball bearings

Bearing number3006-B-TVHSize (mm)30x55x19BrandFAGBore Diameter (mm)30Outer Diameter (mm)55Width (mm)19d30 mmD55 mmB19 mma24.8 mmDa max50.4 mmd135.6 mmda min34.6 mmra max1 mmrmin1 mmα25 ° / Anglem0.16 kg / WeightCr20300 N / Dynamic load rating (radial)C0r15600 N / Static load rating (radial)Cur790 N / radial Fatigue limit loadnG10100 1/min…
Contact Us Now !

Product description

3006-B-TVH FAG 30x55x19mm m 0.16 kg / Weight Angular contact ball bearings

Bearing number3006-B-TVH
Size (mm)30x55x19
BrandFAG
Bore Diameter (mm)30
Outer Diameter (mm)55
Width (mm)19
d30 mm
D55 mm
B19 mm
a24.8 mm
Da max50.4 mm
d135.6 mm
da min34.6 mm
ra max1 mm
rmin1 mm
α25 ° / Angle
m0.16 kg / Weight
Cr20300 N / Dynamic load rating (radial)
C0r15600 N / Static load rating (radial)
Cur790 N / radial Fatigue limit load
nG10100 1/min / Limiting speed

Cross-reference to other manufacturer’s part number

AX 30 47 Needle roller bearings

Weight:0.014 Kg , Ea:42.4 mm , Basic dynamic load rating (C):14.5 kN , Eb:32.7 mm , Basic static load rating (C0):57 kN
249/750-MB-W33 Spherical roller bearings

Calculation factor (Y0):3.13 , Limiting speed:480 r/min , Calculation factor (Y1):3.2 , Calculation factor (e):0.21
ZA-48BWD02A2CA97** Tapered roller bearings

r1 min.:4.5 mm , ABS:+ , r2 min.:3.5 mm , C:40 mm , Weight:0.92 Kg , b:21 mm
3305 Angular contact ball bearings

B:25.4 mm , C:25.4 mm , D:62 mm , Width :25.4mm , d:25 mm
TAF 101716/SG Needle roller bearings

Weight:0.0147 Kg , C:16 mm , Basic dynamic load rating (C):8.23 kN , Da max.:15.4 mm , r min.:0.2 mm
XGB41688P Angular contact ball bearings

D:91 mm , C:44 mm , Weight:1.112 Kg , B:44 mm , d:51 mm
SAC4090B Thrust ball bearings

Angle (α):60 ° , Weight:0.62 Kg , r min.:1 mm , r1 min.:0.6 mm , (Grease) Lubrication Speed:3 100 r/min
51132M Thrust ball bearings

H:31 mm , Outer Diameter :200mm , d:160 mm , D:200 mm , Width :31mm
RT-727 Thrust roller bearings

B:34.925 mm , d:50.8 mm , Bore Diameter :50.8mm , D1:152.4 mm
LMEF30L Linear bearings

Basic dynamic load rating (C):2.49 kN , Tolerance perpendicularity (C):17 , PCD:62 mm , H:10 mm , Weight:0.655 Kg , L:123 mm
