Home > Angular contact ball bearings > 305283 D SKF Manufacturer Item Number 305283 D 230x150x70mm Angular contact ball bearings
305283 D SKF Manufacturer Item Number 305283 D 230x150x70mm  Angular contact ball bearings

305283 D SKF Manufacturer Item Number 305283 D 230x150x70mm Angular contact ball bearings

Bearing number305283 DSize (mm)230x150x70BrandSKFBore Diameter (mm)230Outer Diameter (mm)150Width (mm)70d150 mmD230 mmB70 mmd1181 mmD1208.1 mmb7.8 mmK3 mmr1,2 - min.2 mma138 mmda - min.155 mmDa - max.206 mmra - max.2 mmBasic dynamic load rating - C203 kNBasic static load rating - C0285 kNFatigue load limit - Pu9 kNReference speed2400 r/minLimiting …
Contact Us Now !

Product description

305283 D SKF Manufacturer Item Number 305283 D 230x150x70mm Angular contact ball bearings

Bearing number305283 D
Size (mm)230x150x70
BrandSKF
Bore Diameter (mm)230
Outer Diameter (mm)150
Width (mm)70
d150 mm
D230 mm
B70 mm
d1181 mm
D1208.1 mm
b7.8 mm
K3 mm
r1,2 – min.2 mm
a138 mm
da – min.155 mm
Da – max.206 mm
ra – max.2 mm
Basic dynamic load rating – C203 kN
Basic static load rating – C0285 kN
Fatigue load limit – Pu9 kN
Reference speed2400 r/min
Limiting speed3000 r/min
Calculation factor – kr0.095
Calculation factor – e1.14
Calculation factor – X0.57
Calculation factor – Y00.52
Calculation factor – Y10.55
Calculation factor – Y20.93
CategoryAngular Contact Ball Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram10.776
EAN7316570326932
Product Group – BDIB00152
EnclosureOpen
Flush GroundNo
Rolling ElementBall Bearing
Number of Rows of BallsDouble Row
Precision ClassABEC 1 | ISO P0
Maximum Capacity / Filling SlotNo
Snap RingNo
Cage MaterialSteel
Internal ClearanceC0-Medium
Number of Bearings1 (Single)
Inch – MetricMetric
Long Description150MM Bore; 230MM Outside Diameter; 70MM Width; Open; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; C0-Medium; Steel Cage; 1 (Single)
Other FeaturesTwo Piece Bearing
Category – BDIAngular Contact Ball Bearing
UNSPSC31171531
Harmonized Tariff Code8482.10.50.28
NounBearing
Keyword StringAngular Contact
Manufacturer URLhttp://www.skf.com
Manufacturer Item Number305283 D
Weight / LBS23.36897
Width2.756 Inch | 70 Millimeter
Outside Diameter9.055 Inch | 230 Millimeter
Bore5.906 Inch | 150 Millimeter
d1181 mm
D1208.1 mm
r1,2 min.2 mm
da min.155 mm
Da max.206 mm
ra max.2 mm
Basic dynamic load rating C203 kN
Basic static load rating C0285 kN
Fatigue load limit Pu9 kN
Calculation factor kr0.095
Calculation factor e1.14
Calculation factor X0.57
Calculation factor Y00.52
Calculation factor Y10.55
Calculation factor Y20.93
Mass bearing10.6 kg

Cross-reference to other manufacturer’s part number

W210PPB4 Deep groove ball bearings

D:90 mm , B:30.18 mm , Weight:0.957 Kg , C:30.18 mm , Basic dynamic load rating (C):39.9 kN
TAPR 480 N Plain bearings

d5:160 r/min , Angle:6 ° , Weight:13.97 Kg , Basic dynamic load rating (C):400 kN , Thread (G):M80x2
AST650 81212 Plain bearings

OD Chamfer Length (Co):2.000 , ID Chamfer Angle (B deg.):15 , ID Chamfer Length (Ci):1.200 , Bearing Length Tolerance (B tol.) – -0.10 / -0.30:0.10 / 0.30 , Material:Cast bronze with solid lubricant inserts.
AST090 5050 Plain bearings

OD Chamfer Length (Co):1.800 , ID Chamfer Length (Ci):0.600 , Material:Wrapped bronze with formed lubrication indents. , ID Chamfer Angle (B deg.):45 , Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40
22220CJ Spherical roller bearings

da:119 mm , C:46 mm , Da:160 mm , R:2 mm , B:46 mm
AST11 1412 Plain bearings

Bearing Length Tolerance (B tol.) – +0 / -0.30:+0 / 0.30 , OD Chamfer Length (Co):0.600 , ID Chamfer Length (Ci):0.300 , ID Chamfer Angle (B deg.):30 , Material:Bronze shell with PTFE / Fiber lining
249/710 K30 Spherical roller bearings

Basic static load rating (C0):15288 kN , K:12 mm , (Grease) Lubrication Speed:382.5 r/min , Weight:495 Kg , C:243 mm , Basic dynamic load rating (C):6664 kN
W685ZZ Deep groove ball bearings

(Grease) Lubrication Speed:53000 r/min , Basic dynamic load rating (C):0.97 kN , Weight:0.001 Kg , ra max.:0.15 mm , Basic static load rating (C0):0.36 kN , Da max.:9.8 mm
LMEF8UU Linear bearings

Basic dynamic load rating (C):0.26 kN , L:25 mm , Weight:0.044 Kg , PCD:24 mm , Tolerance perpendicularity (C):12 , H:5 mm
TUW2 24 Plain bearings

D1:42 mm , M:33 mm , h:3 mm , t:1 mm
