3204A-2Z SKF da min. 25.6 mm 20x47x20.6mm  Angular contact ball bearings

3204A-2Z SKF da min. 25.6 mm 20x47x20.6mm Angular contact ball bearings

Bearing number3204A-2ZSize (mm)20x47x20.6BrandSKFBore Diameter (mm)20Outer Diameter (mm)47Width (mm)20.6d20 mmD47 mmB20.6 mmC20.6 mma28 mmd127.7 mmr1 min.1 mmr2 min.1 mmD140.9 mmda min.25.6 mmda max27.5 mmDa max.41.4 mmra max.1 mmWeight0.16 KgBasic dynamic load rating (C)20 kNBasic static load rating (C0)12 kNFatigue load limit (Pu)0.51 Cross-refer…
Contact Us Now !

Product description

3204A-2Z SKF da min. 25.6 mm 20x47x20.6mm Angular contact ball bearings

Bearing number3204A-2Z
Size (mm)20x47x20.6
BrandSKF
Bore Diameter (mm)20
Outer Diameter (mm)47
Width (mm)20.6
d20 mm
D47 mm
B20.6 mm
C20.6 mm
a28 mm
d127.7 mm
r1 min.1 mm
r2 min.1 mm
D140.9 mm
da min.25.6 mm
da max27.5 mm
Da max.41.4 mm
ra max.1 mm
Weight0.16 Kg
Basic dynamic load rating (C)20 kN
Basic static load rating (C0)12 kN
Fatigue load limit (Pu)0.51

Cross-reference to other manufacturer’s part number

2LA-HSE914G/GNP42 Angular contact ball bearings

Angle (α):20 ° , B:16 mm , C:16 mm , D:100 mm , d:70 mm
712147710 Needle roller bearings

D:65.2 mm , Width :14mm , T:14 mm , Outer Diameter :65.2mm , d:45.8 mm , Bore Diameter :45.8mm
LMHP8UU Linear bearings

Tolerance perpendicularity (C):12 , Basic dynamic load rating (C):0.26 kN , â„“:5 Tolerance h14 , Weight:0.04 Kg , W:21 mm
X30213/Y30213 Tapered roller bearings

Basic dynamic load rating (Ca90):21.7 , Basic dynamic load rating (C90):31.4 , Basic dynamic load rating (C1):121 kN , Calculation factor (e):0.4 , Factor (K):1.44
24130CK30E4 Spherical roller bearings

SDM_:200.556 , calcUrl:/BearingGuide/html/calculation.jsp , DI_:176.335 , SBRG:41 , r:2.1 , KBRG:2322
24176W33 Spherical roller bearings

C:243 mm , D:620 mm , B:243 mm , d:380 mm
LME40AJ Linear bearings

Weight:0.705 Kg , W:2.15 mm , L:80 mm , Basic dynamic load rating (C):2.15 kN , B:60.6 mm , D1:59 mm
24122 Spherical roller bearings

Basic dynamic load rating (C):510 kN , K:3 mm , Basic static load rating (C0):735 kN , (Grease) Lubrication Speed:2295 r/min , Weight:7.1 Kg
2208 Self aligning ball bearings

B:23 mm , Basic dynamic load rating (C):31.9 kN , (Grease) Lubrication Speed:7500 r/min , C:23 mm , Basic static load rating (C0):10 kN , Weight:0.51 Kg
T4DB200 Tapered roller bearings

(Oil) Lubrication Speed:1400 r/min , Calculation factor (e):0.47 , Calculation factor (Y):1.27 , (Grease) Lubrication Speed:950 r/min
