3206 A-2RS1TN9/MT33 SKF 62x30x23.8mm  operating temperature range: -40 to +210 °F Angular contact ball bearings

3206 A-2RS1TN9/MT33 SKF 62x30x23.8mm operating temperature range: -40 to +210 °F Angular contact ball bearings

Bearing number3206 A-2RS1TN9/MT33Size (mm)62x30x23.8BrandSKFBore Diameter (mm)62Outer Diameter (mm)30Width (mm)23.8d30 mmD62 mmB23.8 mmd238.7 mmD255.15 mmr1,2 - min.1 mma36 mmda - min.35.6 mmda - max.38.5 mmDa - max.56.4 mmra - max.1 mmBasic dynamic load rating - C30 kNBasic static load rating - C020.4 kNFatigue load limit - Pu0.865 kNLimiting spee…
Contact Us Now !

Product description

3206 A-2RS1TN9/MT33 SKF 62x30x23.8mm operating temperature range: -40 to +210 °F Angular contact ball bearings

Bearing number3206 A-2RS1TN9/MT33
Size (mm)62x30x23.8
BrandSKF
Bore Diameter (mm)62
Outer Diameter (mm)30
Width (mm)23.8
d30 mm
D62 mm
B23.8 mm
d238.7 mm
D255.15 mm
r1,2 – min.1 mm
a36 mm
da – min.35.6 mm
da – max.38.5 mm
Da – max.56.4 mm
ra – max.1 mm
Basic dynamic load rating – C30 kN
Basic static load rating – C020.4 kN
Fatigue load limit – Pu0.865 kN
Limiting speed7500 r/min
Calculation factor – kr0.06
Calculation factor – e0.8
Calculation factor – X0.63
Calculation factor – Y00.66
Calculation factor – Y10.78
Calculation factor – Y21.24
CategoryAngular Contact Ball Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.299
EAN7316570390452
Product Group – BDIB00152
Enclosure2 Seals
Flush GroundNo
Rolling ElementBall Bearing
Number of Rows of BallsDouble Row
Precision ClassABEC 1 | ISO P0
Maximum Capacity / Filling SlotNo
Snap RingNo
Cage MaterialPolyamide
Contact Angle30 Degree
Internal ClearanceC0-Medium
Number of Bearings1 (Single)
Inch – MetricMetric
Long Description30MM Bore; 62MM Outside Diameter; 23.8MM Width; 2 Seals; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; C0-Medium; Polyamide Cage; 30 Degree; 1 (Single)
Other FeaturesNBR Contact Seal | Glass Fibre Reinforced Cage | MT33-Lithium Soap Thickener Grease
Category – BDIAngular Contact Ball Bearing
UNSPSC31171531
Harmonized Tariff Code8482.10.50.28
NounBearing
Keyword StringAngular Contact
Manufacturer URLhttp://www.skf.com
Manufacturer Item Number3206 A-2RS1TN9/MT33
Weight / LBS0.6459
Width0.937 Inch | 23.8 Millimeter
Outside Diameter2.441 Inch | 62 Millimeter
Bore1.181 Inch | 30 Millimeter
bore diameter:30 mm
operating temperature range:-40 to +210 °F
outside diameter:62 mm
cage material:Fiberglass Reinforced Nylon
overall width:0.9375 in
outer ring width:23.8 mm
contact angle:30 °
maximum rpm:7500 RPM
row type & fill slot:Double-Row Non-Fill Slot
finish/coating:Uncoated
internal clearance:C0
precision rating:Not Rated
closure type:Double Seal
fillet radius:1 mm
radial dynamic load capacity:28.6 kN
series:32
radial static load capacity:20-2/5 kN
d238.7 mm
D255.15 mm
r1,2 min.1 mm
da min.35.6 mm
da max.38.5 mm
Da max.56.4 mm
ra max.1 mm
Basic dynamic load rating C30 kN
Basic static load rating C020.4 kN
Fatigue load limit Pu0.865 kN
Calculation factor kr0.06
Calculation factor e0.8
Calculation factor X0.63
Calculation factor Y00.66
Calculation factor Y10.78
Calculation factor Y21.24
Mass bearing0.29 kg
