3210-B-2RSR-TVH FAG Da max. 83 mm 50x90x30.2mm  Angular contact ball bearings

3210-B-2RSR-TVH FAG Da max. 83 mm 50x90x30.2mm Angular contact ball bearings

Bearing number3210-B-2RSR-TVHSize (mm)50x90x30.2BrandFAGBore Diameter (mm)50Outer Diameter (mm)90Width (mm)30.2d50 mmD90 mmB30.2 mmC30.2 mmAngle (α)25 °a45 mmd162 mmr min.1.1 mmD1– mmD280.9 mmda min.57 mmDa max.83 mmra max.1 mmWeight0.693 KgBasic dynamic load rating (C)51 kNBasic static load rating (C0)42.5 kNFatigue load limit (Pu)2.12…
Contact Us Now !

Product description

3210-B-2RSR-TVH FAG Da max. 83 mm 50x90x30.2mm Angular contact ball bearings

Bearing number3210-B-2RSR-TVH
Size (mm)50x90x30.2
BrandFAG
Bore Diameter (mm)50
Outer Diameter (mm)90
Width (mm)30.2
d50 mm
D90 mm
B30.2 mm
C30.2 mm
Angle (α)25 °
a45 mm
d162 mm
r min.1.1 mm
D1– mm
D280.9 mm
da min.57 mm
Da max.83 mm
ra max.1 mm
Weight0.693 Kg
Basic dynamic load rating (C)51 kN
Basic static load rating (C0)42.5 kN
Fatigue load limit (Pu)2.12
Reference speed– r/min

Cross-reference to other manufacturer’s part number

22214 KCW33 Spherical roller bearings

B:31 mm , Basic dynamic load rating (C):148 kN , C:31 mm , (Grease) Lubrication Speed:3600 r/min , Basic static load rating (C0):186 kN , Weight:1.46 Kg
23064EK Cylindrical roller bearings

Calculation factor (e):0.24 , Calculation factor (Y0):2.7 , Calculation factor (Y1):2.76 , (Oil) Lubrication Speed:1100 r/min , (Grease) Lubrication Speed:900 r/min
USPLE204 Bearing units

Weight:0.5 Kg , N1:17 mm , Thread (G):M6x1 , Basic dynamic load rating (C):12.8 kN
16068 Deep groove ball bearings

B:57 mm , C:57 mm , d:340 mm , Outer Diameter :520mm , Width :57mm , D:520 mm
VEB 17 7CE1 Angular contact ball bearings

(Grease) Lubrication Speed:70 000 r/min , Db max:28.6 mm , Weight:0.016 Kg , (Oil) Lubrication Speed:106 000 r/min , Basic static load rating (C0):1.56 kN , Basic dynamic load rating (C):3.32 kN
SF7203 Angular contact ball bearings

C:70.000 mm , B:70.000 mm , D:509.500 mm , d:360.000 mm
AST11 WC12 Plain bearings

Housing Counterbore Diameter Tolerance (HD tol.):+0.12 / 0 , Material:Bronze shell with PTFE / Fiber lining , Housing Counterbore Diameter, Nominal (HD):24.000 , Housing Counterbore Depth Tolerance (Ha tol.) – +0.2 / -0.2:+0.2 / 0.2
AXK 3552 Needle roller bearings

Basic dynamic load rating (C):16.9 kN , D:52 mm , Basic static load rating (C0):80.1 kN , Weight:0.01 Kg , H:2 mm
AST40 250100 Plain bearings

OD Chamfer Length (Co):1.800 , ID Chamfer Angle (B deg.):45 , ID Chamfer Length (Ci):0.600 , Material:Steel shell with PTFE / Polymer Fiber lining , Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40
AST11 WC22 Plain bearings

Housing Counterbore Diameter, Nominal (HD):38.000 , Housing Counterbore Depth Tolerance (Ha tol.) – +0.2 / -0.2:+0.2 / 0.2 , Material:Bronze shell with PTFE / Fiber lining , Housing Counterbore Depth (Ha):1.00 , Housing Counterbore Diameter Tolerance (HD tol.):+0.12 / 0
