Home > Angular contact ball bearings > 3213 A-2Z SKF Inch – Metric Metric 120x65x38.1mm Angular contact ball bearings
3213 A-2Z SKF Inch – Metric Metric 120x65x38.1mm  Angular contact ball bearings

3213 A-2Z SKF Inch – Metric Metric 120x65x38.1mm Angular contact ball bearings

Bearing number3213 A-2ZSize (mm)120x65x38.1BrandSKFBore Diameter (mm)120Outer Diameter (mm)65Width (mm)38.1d65 mmD120 mmB38.1 mmd277.5 mmD2110.65 mmr1,2 - min.1.5 mma71 mmda - min.74 mmda - max.76 mmDa - max.111 mmra - max.1.5 mmBasic dynamic load rating - C80.6 kNBasic static load rating - C073.5 kNFatigue load limit - Pu3.1 kNReference speed4500 …
Contact Us Now !

Product description

3213 A-2Z SKF Inch – Metric Metric 120x65x38.1mm Angular contact ball bearings

Bearing number3213 A-2Z
Size (mm)120x65x38.1
BrandSKF
Bore Diameter (mm)120
Outer Diameter (mm)65
Width (mm)38.1
d65 mm
D120 mm
B38.1 mm
d277.5 mm
D2110.65 mm
r1,2 – min.1.5 mm
a71 mm
da – min.74 mm
da – max.76 mm
Da – max.111 mm
ra – max.1.5 mm
Basic dynamic load rating – C80.6 kN
Basic static load rating – C073.5 kN
Fatigue load limit – Pu3.1 kN
Reference speed4500 r/min
Limiting speed4800 r/min
Calculation factor – kr0.06
Calculation factor – e0.8
Calculation factor – X0.63
Calculation factor – Y00.66
Calculation factor – Y10.78
Calculation factor – Y21.24
CategoryAngular Contact Ball Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram1.624
EAN7316573930686
Product Group – BDIB00152
Enclosure2 Metal Shields
Flush GroundNo
Rolling ElementBall Bearing
Number of Rows of BallsDouble Row
Precision ClassABEC 1 | ISO P0
Maximum Capacity / Filling SlotNo
Snap RingNo
Cage MaterialSteel
Contact Angle30 Degree
Internal ClearanceC0-Medium
Number of Bearings1 (Single)
Inch – MetricMetric
Long Description65MM Bore; 120MM Outside Diameter; 38.1MM Width; 2 Metal Shields; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; C0-Medium; Steel Cage; 30 Degree; 1 (Single)
Category – BDIAngular Contact Ball Bearing
UNSPSC31171531
Harmonized Tariff Code8482.10.50.28
NounBearing
Keyword StringAngular Contact
Manufacturer URLhttp://www.skf.com
Manufacturer Item Number3213 A-2Z
Weight / LBS3.578
Bore2.559 Inch | 65 Millimeter
Width1.5 Inch | 38.1 Millimeter
Outside Diameter4.724 Inch | 120 Millimeter
d277.5 mm
D2110.65 mm
r1,2 min.1.5 mm
da min.74 mm
da max.76 mm
Da max.111 mm
ra max.1.5 mm
Basic dynamic load rating C80.6 kN
Basic static load rating C073.5 kN
Fatigue load limit Pu3.1 kN
Calculation factor kr0.06
Calculation factor e0.8
Calculation factor X0.63
Calculation factor Y00.66
Calculation factor Y10.78
Calculation factor Y21.24
Mass bearing1.75 kg
