3305 A-2ZTN9/MT33 SKF  62x25x25.4mm  Angular contact ball bearings

3305 A-2ZTN9/MT33 SKF 62x25x25.4mm Angular contact ball bearings

Bearing number3305 A-2ZTN9/MT33Size (mm)62x25x25.4BrandSKFBore Diameter (mm)62Outer Diameter (mm)25Width (mm)25.4d25 mmD62 mmB25.4 mmd235.7 mmD253.4 mmr1,2 - min.1.1 mma36 mmda - min.32 mmda - max.35.5 mmDa - max.55 mmra - max.1 mmBasic dynamic load rating - C32 kNBasic static load rating - C020.4 kNFatigue load limit - Pu0.865 kNReference speed110…
Contact Us Now !

Product description

3305 A-2ZTN9/MT33 SKF 62x25x25.4mm Angular contact ball bearings

Bearing number3305 A-2ZTN9/MT33
Size (mm)62x25x25.4
BrandSKF
Bore Diameter (mm)62
Outer Diameter (mm)25
Width (mm)25.4
d25 mm
D62 mm
B25.4 mm
d235.7 mm
D253.4 mm
r1,2 – min.1.1 mm
a36 mm
da – min.32 mm
da – max.35.5 mm
Da – max.55 mm
ra – max.1 mm
Basic dynamic load rating – C32 kN
Basic static load rating – C020.4 kN
Fatigue load limit – Pu0.865 kN
Reference speed11000 r/min
Limiting speed11000 r/min
Calculation factor – kr0.07
Calculation factor – e0.8
Calculation factor – X0.63
Calculation factor – Y00.66
Calculation factor – Y10.78
Calculation factor – Y21.24
CategoryAngular Contact Ball Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.361
EAN7316570807530
Product Group – BDIB00152
Enclosure2 Metal Shields
Flush GroundNo
Rolling ElementBall Bearing
Number of Rows of BallsDouble Row
Precision ClassABEC 1 | ISO P0
Maximum Capacity / Filling SlotNo
Snap RingNo
Cage MaterialPolyamide
Contact Angle30 Degree
Internal ClearanceC0-Medium
Number of Bearings1 (Single)
Inch – MetricMetric
Long Description25MM Bore; 62MM Outside Diameter; 25.4MM Width; 2 Metal Shields; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; C0-Medium; Polyamide Cage; 30 Degree; 1 (Single)
Other FeaturesGlass Fibre Reinforced Cage | MT33-Lithium Soap Thickener Grease
Category – BDIAngular Contact Ball Bearing
UNSPSC31171531
Harmonized Tariff Code8482.10.50.28
NounBearing
Keyword StringAngular Contact
Manufacturer URLhttp://www.skf.com
Manufacturer Item Number3305 A-2ZTN9/MT33
Weight / LBS0.7958
Outside Diameter2.441 Inch | 62 Millimeter
Bore0.984 Inch | 25 Millimeter
Width1 Inch | 25.4 Millimeter
d235.7 mm
D253.4 mm
r1,2 min.1.1 mm
da min.32 mm
da max.35.5 mm
Da max.55 mm
ra max.1 mm
Basic dynamic load rating C32 kN
Basic static load rating C020.4 kN
Fatigue load limit Pu0.865 kN
Calculation factor kr0.07
Calculation factor e0.8
Calculation factor X0.63
Calculation factor Y00.66
Calculation factor Y10.78
Calculation factor Y21.24
Mass bearing0.35 kg
