3305-B-TVH FAG Fatigue load limit (Pu) 0.9 25x62x25.4mm  Angular contact ball bearings

3305-B-TVH FAG Fatigue load limit (Pu) 0.9 25x62x25.4mm Angular contact ball bearings

Bearing number3305-B-TVHSize (mm)25x62x25.4BrandFAGBore Diameter (mm)25Outer Diameter (mm)62Width (mm)25.4d25 mmD62 mmB25.4 mmC25.4 mmAngle (α)25 °a31 mmd137.2 mmr min.1.1 mmD150 mmD2– mmda min.32 mmDa max.55 mmra max.1 mmWeight0.353 KgBasic dynamic load rating (C)30 kNBasic static load rating (C0)20 kNFatigue load limit (Pu)0.9Referenc…
Contact Us Now !

Product description

3305-B-TVH FAG Fatigue load limit (Pu) 0.9 25x62x25.4mm Angular contact ball bearings

Bearing number3305-B-TVH
Size (mm)25x62x25.4
BrandFAG
Bore Diameter (mm)25
Outer Diameter (mm)62
Width (mm)25.4
d25 mm
D62 mm
B25.4 mm
C25.4 mm
Angle (α)25 °
a31 mm
d137.2 mm
r min.1.1 mm
D150 mm
D2– mm
da min.32 mm
Da max.55 mm
ra max.1 mm
Weight0.353 Kg
Basic dynamic load rating (C)30 kN
Basic static load rating (C0)20 kN
Fatigue load limit (Pu)0.9
Reference speed8 500 r/min

Cross-reference to other manufacturer’s part number

1213 ETN9 Self aligning ball bearings

Calculation factor Y2:5.4 , Mass bearing:1.15 kg , Calculation factor kr:0.04 , Calculation factor e:0.18 , Calculation factor Y1:3.5 , Calculation factor Y0:3.6
UKF305 Bearing units

Basic dynamic load rating (C):21.2 kN , A2:16 mm , Thread (G):M14 , Weight:1.4 Kg , Basic static load rating (C0):10.9 kN , N:16 mm
220RF03 Cylindrical roller bearings

C:88 mm , B:88 mm , F:261 mm , r max:4 mm , E:419 mm , D:460 mm
10-2022 Deep groove ball bearings

D:38 mm , Width :19mm , B:19 mm , d:15 mm
AST090 17060 Plain bearings

Material:Wrapped bronze with formed lubrication indents. , ID Chamfer Length (Ci):0.600 , OD Chamfer Length (Co):1.800 , ID Chamfer Angle (B deg.):45
B-1610 Needle roller bearings

Basic dynamic load rating (C):21.2 kN , D:31.750 mm , C:15.88 mm , Weight:0.026 Kg
SI 25 C Plain bearings

d5:42 r/min , Angle:7 ° , Basic dynamic load rating (C):51 kN , Weight:0.64 Kg
11208G15 Self aligning ball bearings

B:56 mm , d:40.000 mm , Width :56mm , Outer Diameter :80.000mm , D:80.000 mm , C:18 mm
UST212+WB Bearing units

Basic dynamic load rating (C):52.5 kN , A2:76.8 mm , Weight:20 Kg , T:6 mm
AST20 44IB56 Plain bearings

Material:Carbon steel shell with POM plastic liner , ID Chamfer Length (Ci):0.031 , Lube Hole Dia. (dl):0.313 , ID Chamfer Angle (B deg.):45
