3307-BD-TVH FAG 35x80x34.9mm  α 30 ° / Angle Angular contact ball bearings

3307-BD-TVH FAG 35x80x34.9mm α 30 ° / Angle Angular contact ball bearings

Bearing number3307-BD-TVHSize (mm)35x80x34.9BrandFAGBore Diameter (mm)35Outer Diameter (mm)80Width (mm)34.9d35 mmD80 mmB34.9 mma47.986 mmD168.9 mmDa max71 mmd151.8 mmda min44 mmra max1.5 mmrmin1.5 mmα30 ° / Anglem0.706 kg / WeightCr55000 N / Dynamic load rating (radial)C0r36500 N / Static load rating (radial)Cur2460 N / Fatigue limit load…
Contact Us Now !

Product description

3307-BD-TVH FAG 35x80x34.9mm α 30 ° / Angle Angular contact ball bearings

Bearing number3307-BD-TVH
Size (mm)35x80x34.9
BrandFAG
Bore Diameter (mm)35
Outer Diameter (mm)80
Width (mm)34.9
d35 mm
D80 mm
B34.9 mm
a47.986 mm
D168.9 mm
Da max71 mm
d151.8 mm
da min44 mm
ra max1.5 mm
rmin1.5 mm
α30 ° / Angle
m0.706 kg / Weight
Cr55000 N / Dynamic load rating (radial)
C0r36500 N / Static load rating (radial)
Cur2460 N / Fatigue limit load. radial
nG9000 1/min / Limiting speed
nB8100 1/min / Reference speed

Cross-reference to other manufacturer’s part number

AST090 21080 Plain bearings

OD Chamfer Length (Co):1.800 , ID Chamfer Angle (B deg.):45 , ID Chamfer Length (Ci):0.600 , Material:Wrapped bronze with formed lubrication indents.
U199/U160L Tapered roller bearings

r:1.3 mm , B:19.5 mm , C:13 mm , R:2.3 mm
2314 Self aligning ball bearings

d:70 mm , C:51 mm , D:150 mm , B:51 mm , Width :51mm
B-2816 Needle roller bearings

Basic static load rating (C0):121 kN , (Grease) Lubrication Speed:2400 r/min , D:53.975 mm , C:25.4 mm , Weight:0.11 Kg , Basic dynamic load rating (C):53.4 kN
2LA-HSE906CG/GNP42 Angular contact ball bearings

B:9 mm , D:47 mm , d:30 mm , C:9 mm , Angle (α):15 °
24144RHAK30 Spherical roller bearings

Calculation factor (Y0):1.65 , Calculation factor (e):0.4 , Calculation factor (Y1):1.69 , (Grease) Lubrication Speed:880 r/min , (Oil) Lubrication Speed:1200 r/min , Basic static load rating (C0):3550 kN
LMKM35 Linear bearings

Basic dynamic load rating (C):2.65 kN , â„“:62.5 Tolerance h14 , PCD:67 mm , Tolerance perpendicularity (C):25 , Weight:0.97 Kg
40TAF11 Thrust ball bearings

Basic static load rating (C0):118 kN , Basic dynamic load rating (C):152 kN , r1 min.:1 mm , r min.:2 mm , Weight:1.28 Kg
25TAD20 Thrust ball bearings

ra max.:0.6 mm , Weight:0.197 Kg , (Grease) Lubrication Speed:8000 r/min , Basic dynamic load rating (C):10.7 kN , Basic static load rating (C0):19.9 kN
201KTD2 Deep groove ball bearings

d:13 mm , Basic dynamic load rating (C):7.68 kN , Weight:0.045 Kg , C:12.7 mm , D:32 mm , B:12.19 mm
