51111 NSK 55x78x16mm  cage material: Steel Cage Thrust ball bearings

51111 NSK 55x78x16mm cage material: Steel Cage Thrust ball bearings

Bearing number51111Size (mm)55x78x16BrandNSKBore Diameter (mm)55Outer Diameter (mm)78Width (mm)16d55 mmD78 mmT16 mmd178 mmr min.0.6 mmD157 mmda min.69 mmDa max.64 mmra max.0.6 mmWeight0.227 KgBasic dynamic load rating (C)35 kNBasic static load rating (C0)93 kN(Grease) Lubrication Speed2800 r/minCategoryThrust Ball BearingBDI Inventory0.0Manufacture…
Contact Us Now !

Product description

51111 NSK 55x78x16mm cage material: Steel Cage Thrust ball bearings

Bearing number51111
Size (mm)55x78x16
BrandNSK
Bore Diameter (mm)55
Outer Diameter (mm)78
Width (mm)16
d55 mm
D78 mm
T16 mm
d178 mm
r min.0.6 mm
D157 mm
da min.69 mm
Da max.64 mm
ra max.0.6 mm
Weight0.227 Kg
Basic dynamic load rating (C)35 kN
Basic static load rating (C0)93 kN
(Grease) Lubrication Speed2800 r/min
CategoryThrust Ball Bearing
BDI Inventory0.0
Manufacturer NameNSK
Minimum Buy QuantityN/A
Weight / Kilogram0.235
EAN0029176028960
Product Group – BDIB00308
Rolling ElementBall Bearing
Thrust BearingYes
Single or Double DirectionSingle Direction
BandedNo
Cage MaterialSteel
Precision ClassNon-Precision
Component DescriptionRoller Assembly Plus Raceways
Other FeaturesSingle Row | With Flat Seat
Long Description55MM Bore 1; 57MM Bore 2; 78MM Outside Diameter; 16MM Height; Ball Bearing; Single Direction; Not Banded; Steel Cage; Non-Precision
Inch – MetricMetric
Category – BDIThrust Ball Bearings
UNSPSC31171552
Harmonized Tariff Code8482.10.50.08
NounBearing
Keyword StringBall Thrust
Manufacturer URLhttp://www.nskamericas.com
Manufacturer Item Number51111
Weight / LBS0.50045
Bore 12.165 Inch | 55 Millimeter
Height0.63 Inch | 16 Millimeter
Bore 22.244 Inch | 57 Millimeter
Outside Diameter3.071 Inch | 78 Millimeter
Overall Height with Aligning Washer0 Inch | 0 Millimeter
bore diameter:55 mm
static load capacity:20900 lbf
outside diameter:78 mm
dynamic load capacity:7900 lbf
overall width:16 mm
operating temperature range:Maximum of +120 °C
thrust bearing type:Single-Direction
maximum rpm:4300 rpm
outside diameter design:Straight
cage material:Steel Cage
separable or banded:Separable
fillet radius:.6 mm
race type:Flat
series:51100
precision rating:ABEC1. P0
SRI4.3
hidYobi51111
LangID1
D_78
SREX0.04
C35
B_16
CADhttp://service.web2cad.co.jp/pcom/?Maker=NSK_RB&info=nsk_rb/roller_bearings/thrust_bearings/single_direction_tbb/with_flat_seet_asmtab.prj&varset={ORDER=51111}.{SD=55}.{D=78}.{T=16}.{SR=0.6}.{CAN=35000}.{COAN=93000}.{CA=3600}.{COA=9500}.{GRE=2800}.{OIL=4300}.{SD1=78}.{D1=57}.{SDA=69}.{DA=64}.{SRA=0.6}.{MASS=0.227}
hidTableecat_NSSDTB
Oil rpm4300
SRE4.3
mass0.227
GRS rpm2800
ra0.6
SRIX0.04
D_a64
SRIN0
C093
SREN0
D_157
Prod_Type3TB_SD_WFS
da69
DA_7.938
Z_24
yobi51111
SDM_66.5
r0.6
T_16
KBRG5111
calcUrl/BearingGuide/html/calculation.jsp
