Home > Thrust ball bearings > 51113 SKF 65x90x18mm outside diameter design: Straight Thrust ball bearings
51113 SKF 65x90x18mm  outside diameter design: Straight Thrust ball bearings

51113 SKF 65x90x18mm outside diameter design: Straight Thrust ball bearings

Bearing number51113Size (mm)65x90x18BrandSKFBore Diameter (mm)65Outer Diameter (mm)90Width (mm)18d65 mmD90 mmH18 mmd190 mmr1 min.1 mmr2 min.1 mmD167 mmda min.80 mmDa max.75 mmra max.1 mmWeight0.33 KgBasic dynamic load rating (C)37.7 kNBasic static load rating (C0)108 kNFatigue load limit (Pu)4Reference speed3400 r/minLimiting speed4800 r/minCategor…
Contact Us Now !

Product description

51113 SKF 65x90x18mm outside diameter design: Straight Thrust ball bearings

Bearing number51113
Size (mm)65x90x18
BrandSKF
Bore Diameter (mm)65
Outer Diameter (mm)90
Width (mm)18
d65 mm
D90 mm
H18 mm
d190 mm
r1 min.1 mm
r2 min.1 mm
D167 mm
da min.80 mm
Da max.75 mm
ra max.1 mm
Weight0.33 Kg
Basic dynamic load rating (C)37.7 kN
Basic static load rating (C0)108 kN
Fatigue load limit (Pu)4
Reference speed3400 r/min
Limiting speed4800 r/min
CategoryThrust Ball Bearing
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram0.341
EAN7316576677519
Product Group – BDIB00308
Rolling ElementBall Bearing
Thrust BearingYes
Single or Double DirectionSingle Direction
BandedNo
Cage MaterialSteel
Precision ClassABEC 1 | ISO P0
Component DescriptionRoller Assembly Plus Raceways
Other FeaturesSingle Row
Long Description65MM Bore 1; 67MM Bore 2; 90MM Outside Diameter; 18MM Height; Ball Bearing; Single Direction; Not Banded; Steel Cage; ABEC 1 | ISO P0 Precision
Inch – MetricMetric
Category – BDIThrust Ball Bearings
UNSPSC31171507
Harmonized Tariff Code8482.10.50.08
NounBearing
Keyword StringBall Thrust
Manufacturer URLhttp://www.skf.com
Manufacturer Item Number51113
Weight / LBS0.75
Height0.709 Inch | 18 Millimeter
Bore 12.559 Inch | 65 Millimeter
Overall Height with Aligning Washer0 Inch | 0 Millimeter
Outside Diameter3.543 Inch | 90 Millimeter
Bore 22.638 Inch | 67 Millimeter
bore diameter:65 mm
static load capacity:108 kN
outside diameter:90 mm
dynamic load capacity:37.7 kN
overall width:18 mm
maximum rpm:4800 RPM
thrust bearing type:Single-Direction
cage material:Steel
outside diameter design:Straight
fillet radius:1 mm
separable or banded:Separable
series:511
precision rating:ABEC 1 (ISO Class Normal)
d190 mm
D167 mm
r1,2 min.1 mm
da min.80 mm
Da max.75 mm
ra max.1 mm
Basic dynamic load rating C37.7 kN
Basic static load rating C0108 kN
Fatigue load limit Pu4 kN
Minimum load factor A0.06
Mass bearing (including seat washer where applicable)0.33 kg
