Home > Plain Bearings > AST090 11090 AST Bearing Bore after Mounting (di) – 110 +0.087 / -0 110 +0.087 / 0 Plain bearings
AST090 11090 AST  Bearing Bore after Mounting (di) – 110 +0.087 / -0 110 +0.087 / 0 Plain bearings

AST090 11090 AST Bearing Bore after Mounting (di) – 110 +0.087 / -0 110 +0.087 / 0 Plain bearings

Bearing numberAST090 11090BrandASTBore Diameter (mm)110Outer Diameter (mm)115Bearing TypestraightShaft Dia., Nominal (d)110.0000Shaft Size (ds) - 110 -0.120 / -0.155110 0.120 / 0.155Housing Bore Dia. (Dh) - 115 +0.035 / -0115 +0.035 / 0Bearing Outside Diameter, Nominal(Do)115.000Bearing Bore after Mounting (di) - 110 +0.087 / -0110 +0.087 / 0Wall T…
Contact Us Now !

Product description

AST090 11090 AST Bearing Bore after Mounting (di) – 110 +0.087 / -0 110 +0.087 / 0 Plain bearings

Bearing numberAST090 11090
BrandAST
Bore Diameter (mm)110
Outer Diameter (mm)115
Bearing Typestraight
Shaft Dia., Nominal (d)110.0000
Shaft Size (ds) – 110 -0.120 / -0.155110 0.120 / 0.155
Housing Bore Dia. (Dh) – 115 +0.035 / -0115 +0.035 / 0
Bearing Outside Diameter, Nominal(Do)115.000
Bearing Bore after Mounting (di) – 110 +0.087 / -0110 +0.087 / 0
Wall Thickness (S3)2.500
Bearing Length, Nominal (B)90.000
Bearing Length Tolerance (B tol.) – +0 / -0.40+0 / 0.40
OD Chamfer Length (Co)1.800
ID Chamfer Angle (B deg.)45
ID Chamfer Length (Ci)0.600
MaterialWrapped bronze with formed lubrication indents.

Cross-reference to other manufacturer’s part number

15100/15250 Tapered roller bearings

Bore Diameter :25.4mm , d:25.4 mm , D:63.5 mm , Outer Diameter :63.5mm , Brand:Fersa , Width :20.638mm
K,81115LPB Thrust roller bearings

Eb:95 mm , Ea:80 mm , Basic dynamic load rating (C):86.1 kN , Weight:0.091 Kg , Basic static load rating (C0):305 kN
3203-B-TVH Angular contact ball bearings

Basic static load rating (C0):9 kN , Basic dynamic load rating (C):14.6 kN , Weight:0.093 Kg , Fatigue load limit (Pu):0.42 , Reference speed:15 400 r/min
LME20AJ Linear bearings

L:45 mm , Weight:0.091 Kg , W:1.6 mm , D1:30.3 mm , Basic dynamic load rating (C):0.86 kN
NKXR40-Z Complex bearings

Category:Ball Bearings , BDI Inventory:0.0 , Manufacturer Name:SCHAEFFLER GROUP , Minimum Buy Quantity:N/A , Product Group – BDI:B00234 , Weight / Kilogram:0.256
UKFL212 Bearing units

Bolt (G):M20 , L:48 mm , S:23 mm , G:18 mm
29452 M Thrust roller bearings

C:64 mm , Weight:104 Kg , Basic dynamic load rating (C):3510 kN , Basic static load rating (C0):12900 kN , (Grease) Lubrication Speed:500 r/min
NUP 2311 ECP Thrust ball bearings

Calculation factor kr:0.25 , Axial load factor Y:0.4 , Basic static load rating C0:232 kN , Mass bearing:2.31 kg , Fatigue load limit Pu:30.5 kN , Limiting value e:0.3
LMKM50 Linear bearings

Basic dynamic load rating (C):6.08 kN , â„“:89.5 Tolerance h14 , Tolerance perpendicularity (C):25 , Weight:3.5 Kg
SFEW80ES Plain bearings

r min.:1 mm , Weight:15.33 Kg , C1:60 mm , Basic dynamic load rating (C):400 kN , Angle:4 ° , l2 max.:231 mm
