AST090 3525 AST  ID Chamfer Angle (B deg.) 35 Plain bearings

AST090 3525 AST ID Chamfer Angle (B deg.) 35 Plain bearings

Bearing numberAST090 3525BrandASTBore Diameter (mm)35Outer Diameter (mm)39Bearing TypestraightShaft Dia., Nominal (d)35.0000Shaft Size (ds) - 35 -0.080 / -0.10535 0.080 / 0.105Housing Bore Dia. (Dh) - 39 +0.025 / -039 +0.025 / 0Bearing Outside Diameter, Nominal(Do)39.000Bearing Bore after Mounting (di) - 35 +0.062 / -035 +0.062 / 0Wall Thickness (S…
Contact Us Now !

Product description

AST090 3525 AST ID Chamfer Angle (B deg.) 35 Plain bearings

Bearing numberAST090 3525
BrandAST
Bore Diameter (mm)35
Outer Diameter (mm)39
Bearing Typestraight
Shaft Dia., Nominal (d)35.0000
Shaft Size (ds) – 35 -0.080 / -0.10535 0.080 / 0.105
Housing Bore Dia. (Dh) – 39 +0.025 / -039 +0.025 / 0
Bearing Outside Diameter, Nominal(Do)39.000
Bearing Bore after Mounting (di) – 35 +0.062 / -035 +0.062 / 0
Wall Thickness (S3)2.000
Bearing Length, Nominal (B)25.000
Bearing Length Tolerance (B tol.) – +0 / -0.40+0 / 0.40
OD Chamfer Length (Co)1.200
ID Chamfer Angle (B deg.)35
ID Chamfer Length (Ci)0.500
MaterialWrapped bronze with formed lubrication indents.

Cross-reference to other manufacturer’s part number

24136CK30W33 Spherical roller bearings

Max Speed (Oil) (X000 RPM):1 , Max Speed (Grease) (X000 RPM):1 , Material:52100 Chrome steel. or equivalent , Weight (g):33.200.00
2LA-HSE919G/GNP42 Angular contact ball bearings

d:95 mm , Outer Diameter :130mm , Width :18mm , Bore Diameter :95mm
15101/15245 Tapered roller bearings

D:62 mm , Bore Diameter :25.4mm , d:25.4 mm , Outer Diameter :62mm , Width :19.05mm
LBBR 8-2LS Linear bearings

D:15 mm , Fw:8 mm , Basic dynamic load rating (C):0.49 kN , Weight:0.007 Kg , C:24 mm , Width :24mm
160FSF230 Plain bearings

Basic dynamic load rating (C):1250 kN , Angle:8 ° , r1 min.:1 mm , Weight:14 Kg
24164RHA Spherical roller bearings

ra(max):4 , Y2:2.52 , Y1:1.70 , Y0:1.66 , (Refer.)Mass(kg):199 , e:0.40
AST090 14570 Plain bearings

ID Chamfer Angle (B deg.):45 , ID Chamfer Length (Ci):0.600 , Material:Wrapped bronze with formed lubrication indents. , OD Chamfer Length (Co):1.800
190RN02 Cylindrical roller bearings

C:55 mm , r max:3 mm , E:314 mm , B:55 mm
B3016 Needle roller bearings

Basic static load rating (C0):124 kN , C:25.4 mm , D:57.15 mm , Weight:0.114 Kg , Basic dynamic load rating (C):47.7 kN
LMFP30 Linear bearings

Tolerance perpendicularity (C):15 , Basic dynamic load rating (C):1.56 kN , â„“:10 Tolerance h14 , Weight:0.46 Kg
