AST090 8535 AST  Wall Thickness (S3) 2.500 Plain bearings

AST090 8535 AST Wall Thickness (S3) 2.500 Plain bearings

Bearing numberAST090 8535BrandASTBore Diameter (mm)85Outer Diameter (mm)90Bearing TypestraightShaft Dia., Nominal (d)85.0000Shaft Size (ds) - 85 -0.120 / -0.15585 0.120 / 0.155Housing Bore Dia. (Dh) - 90 +0.035 / -090 +0.035 / 0Bearing Outside Diameter, Nominal(Do)90.000Bearing Bore after Mounting (di) - 85 +0.087 / -085 +0.087 / 0Wall Thickness (S…
Contact Us Now !

Product description

AST090 8535 AST Wall Thickness (S3) 2.500 Plain bearings

Bearing numberAST090 8535
BrandAST
Bore Diameter (mm)85
Outer Diameter (mm)90
Bearing Typestraight
Shaft Dia., Nominal (d)85.0000
Shaft Size (ds) – 85 -0.120 / -0.15585 0.120 / 0.155
Housing Bore Dia. (Dh) – 90 +0.035 / -090 +0.035 / 0
Bearing Outside Diameter, Nominal(Do)90.000
Bearing Bore after Mounting (di) – 85 +0.087 / -085 +0.087 / 0
Wall Thickness (S3)2.500
Bearing Length, Nominal (B)35.000
Bearing Length Tolerance (B tol.) – +0 / -0.40+0 / 0.40
OD Chamfer Length (Co)1.800
ID Chamfer Angle (B deg.)45
ID Chamfer Length (Ci)0.600
MaterialWrapped bronze with formed lubrication indents.

Cross-reference to other manufacturer’s part number

SDE30AJ Linear bearings

W:1.85 mm , Basic dynamic load rating (C):1470 kN , Weight:0.34 Kg , L:68 mm
B1912 Needle roller bearings

Fw:30.162 mm , C:19.05 mm , Basic static load rating (C0):55.7 kN , D:38.1 mm , Weight:0.046 Kg , Basic dynamic load rating (C):26.2 kN
3308-2RS Angular contact ball bearings

C:36.5 mm , d:40 mm , D:90 mm , B:36.5 mm
29238-E1-MB Thrust roller bearings

Reference speed:1 330 r/min , ra max.:2 mm , Weight:8.3 Kg , Basic dynamic load rating (C):600 kN , Db min.:274 mm , Basic static load rating (C0):2 500 kN
23028AX Cylindrical roller bearings

Calculation factor (Y0):2.69 , Calculation factor (Y1):2.75 , (Oil) Lubrication Speed:3900 r/min , Calculation factor (e):0.25
100034X/100072 Tapered roller bearings

Da:64 mm , Weight:0.38 Kg , r:2 mm , R:2 mm , F:5.25 mm , da:45 mm
VEX 50 /S 7CE3 Angular contact ball bearings

Weight:0.25 Kg , (Grease) Lubrication Speed:23 000 r/min , Basic dynamic load rating (C):14.8 kN , Basic static load rating (C0):10 kN
TR407215 Tapered roller bearings

Basic static load rating (C0):54 kN , Basic dynamic load rating (C):48 kN , Calculation factor (e):0.4 , Calculation factor (Y):1.5 , (Oil) Lubrication Speed:6800 r/min , (Grease) Lubrication Speed:5000 r/min
SI40ES Plain bearings

Basic dynamic load rating (C):99 kN , Weight:2.1 Kg , W:60 mm , Angle:7 ° , C1 max:24 mm , Thread (G):M39×3
24134-CE-K30-W33 Spherical roller bearings

Basic static load rating (C0):1864 kN , Calculation factor (Y1):1.8 , Calculation factor (e):0.37 , Limiting speed:1900 r/min , Calculation factor (Y0):1.76 , Basic dynamic load rating (C):1076 kN
