AST11 7570 AST  OD Chamfer Length (Co) 1.800 Plain bearings

AST11 7570 AST OD Chamfer Length (Co) 1.800 Plain bearings

Bearing numberAST11 7570BrandASTBore Diameter (mm)75Outer Diameter (mm)80Bearing TypestraightShaft Dia., Nominal (d)75.0000Shaft Size (ds) - 75 -0.03 / -0.0675 0.03 / 0.06Housing Bore Dia. (Dh)80 +0.030 / +0Bearing Outside Diameter, Nominal(Do)80.000Bearing Outside Diameter Tolerance (Do tol.)80.1 / 80.055Bearing Bore after Mounting (di)75.11 / 74.…
Contact Us Now !

Product description

AST11 7570 AST OD Chamfer Length (Co) 1.800 Plain bearings

Bearing numberAST11 7570
BrandAST
Bore Diameter (mm)75
Outer Diameter (mm)80
Bearing Typestraight
Shaft Dia., Nominal (d)75.0000
Shaft Size (ds) – 75 -0.03 / -0.0675 0.03 / 0.06
Housing Bore Dia. (Dh)80 +0.030 / +0
Bearing Outside Diameter, Nominal(Do)80.000
Bearing Outside Diameter Tolerance (Do tol.)80.1 / 80.055
Bearing Bore after Mounting (di)75.11 / 74.99
Average Clearance (Cd)0.0950
Wall Thickness (S3)2.505
Bearing Length, Nominal (B)70.000
Bearing Length Tolerance (B tol.) – +0 / -0.40+0 / 0.40
OD Chamfer Length (Co)1.800
ID Chamfer Angle (B deg.)45
ID Chamfer Length (Ci)0.600
MaterialBronze shell with PTFE / Fiber lining
