AST20 3530 AST  Bearing Length, Nominal (B) 30.000 Plain bearings

AST20 3530 AST Bearing Length, Nominal (B) 30.000 Plain bearings

Bearing numberAST20 3530BrandASTBore Diameter (mm)35Outer Diameter (mm)39Bearing TypestraightShaft Dia., Nominal (d)35.0000Shaft Size (ds) - 35 +0 / -0/03935 +0 / 0/039Housing Bore Dia. (Dh) - 39 +0.025 / -039 +0.025 / 0Bearing Outside Diameter, Nominal(Do)39.000Bearing Outside Diameter Tolerance (Do tol.)39.085 / 39.045Bearing Bore after Mounting …
Contact Us Now !

Product description

AST20 3530 AST Bearing Length, Nominal (B) 30.000 Plain bearings

Bearing numberAST20 3530
BrandAST
Bore Diameter (mm)35
Outer Diameter (mm)39
Bearing Typestraight
Shaft Dia., Nominal (d)35.0000
Shaft Size (ds) – 35 +0 / -0/03935 +0 / 0/039
Housing Bore Dia. (Dh) – 39 +0.025 / -039 +0.025 / 0
Bearing Outside Diameter, Nominal(Do)39.000
Bearing Outside Diameter Tolerance (Do tol.)39.085 / 39.045
Bearing Bore after Mounting (di)35.155 / 35.060
Average Clearance (Cd)0.1270
Wall Thickness (S3)1.953
Bearing Length, Nominal (B)30.000
Bearing Length Tolerance (B tol.) – +0 / -0.40+0 / 0.40
OD Chamfer Length (Co)1.200
ID Chamfer Angle (B deg.)30
ID Chamfer Length (Ci)0.500
Lube Hole Dia. (dl)6.000
MaterialCarbon steel shell with POM plastic liner

Cross-reference to other manufacturer’s part number

B-66 Needle roller bearings

Basic static load rating (C0):7.61 kN , Weight:0.005 Kg , Basic dynamic load rating (C):5.83 kN , (Grease) Lubrication Speed:4600 r/min
SL183034 Cylindrical roller bearings

D1:232.7 mm , d1:198.1 mm , Basic dynamic load rating (C):710 kN , Basic static load rating (C0):1070 kN , S:7 mm , Weight:12.2 Kg
RAX 740 Complex bearings

Dynamic load rating axial (C):20.4 kN , Weight:0.086 Kg , Dynamic load rating radial (C):26.2 kN , Static load rating axial (C0):96 kN , Static load rating radial (C0):51 kN , Eb:43 mm
ZGB 45X53X40 Plain bearings

Weight:0.17 Kg , Basic dynamic load rating (C):540 kN , B:40 mm , D:53 mm , f:2 mm
260RU02 Cylindrical roller bearings

r max:4 mm , B:80 mm , C:80 mm , F:300 mm , D:480 mm , E:440 mm
100034X/100076X Tapered roller bearings

R:2 mm , Weight:0.38 Kg , da:45 mm , Da:64 mm
1219 K Self aligning ball bearings

(Grease) Lubrication Speed:3825 r/min , C:32 mm , B:32 mm , Basic static load rating (C0):26.46 kN , Basic dynamic load rating (C):62.43 kN , Weight:3.1 Kg
FYT 1.1/2 FM Bearing units

Nominal Bolt Circle Diameter Round:5.7 Inch | 144 Millimeter , Bore:1.5 Inch | 38.1 Millimeter , Length Thru Bore:1.719 Inch | 43.663 Millimeter , Cartridge Pilot Depth:0 Inch | 0 Millimeter , Bolt Spacing:5.656 Inch | 143.67 Millimeter
WJ-809624 Needle roller bearings

Shaft dia.(h5)(min.):126.982 , Housing bore dia(G6)(max.):152.438 , Shaft dia.(h5)(max.):127.000 , (Refer.)Mass(kg):1.018 , Oil lub.:3400 , Housing bore dia(G6)(min.):152.415
140BNR19S Angular contact ball bearings

Basic dynamic load rating (C):60 kN , (Grease) Lubrication Speed:8 500 r/min , Basic static load rating (C0):61.5 kN , (Oil) Lubrication Speed:12 200 r/min
