AST40 3240 AST  Bearing Bore after Mounting (di) 32.085 / 31.99 Plain bearings

AST40 3240 AST Bearing Bore after Mounting (di) 32.085 / 31.99 Plain bearings

Bearing numberAST40 3240BrandASTBore Diameter (mm)32Outer Diameter (mm)36Bearing TypestraightShaft Dia., Nominal (d)32.0000Shaft Size (ds) - 32 -0.025 / -0.0532 0.025 / 0.05Housing Bore Dia. (Dh)36 +0.025 / +0Bearing Outside Diameter, Nominal(Do)36.000Bearing Outside Diameter Tolerance (Do tol.)36.085 / 36.045Bearing Bore after Mounting (di)32.085 …
Contact Us Now !

Product description

AST40 3240 AST Bearing Bore after Mounting (di) 32.085 / 31.99 Plain bearings

Bearing numberAST40 3240
BrandAST
Bore Diameter (mm)32
Outer Diameter (mm)36
Bearing Typestraight
Shaft Dia., Nominal (d)32.0000
Shaft Size (ds) – 32 -0.025 / -0.0532 0.025 / 0.05
Housing Bore Dia. (Dh)36 +0.025 / +0
Bearing Outside Diameter, Nominal(Do)36.000
Bearing Outside Diameter Tolerance (Do tol.)36.085 / 36.045
Bearing Bore after Mounting (di)32.085 / 31.99
Average Clearance (Cd)0.0750
Wall Thickness (S3)2.005
Bearing Length, Nominal (B)40.000
Bearing Length Tolerance (B tol.) – +0 / -0.40+0 / 0.40
OD Chamfer Length (Co)1.200
ID Chamfer Angle (B deg.)30
ID Chamfer Length (Ci)0.500
MaterialSteel shell with PTFE / Polymer Fiber lining

Cross-reference to other manufacturer’s part number

SIKAC12M/VZ019 Plain bearings

Weight:0.11 Kg , Basic dynamic load rating (C):13.4 kN , Angle:13 ° , Thread (G):M12x1.25 Tolerance 6H
SL06-026 Cylindrical roller bearings

D:200.000 mm , C:65.000 mm , d:130.000 mm , B:65.000 mm
130RU03 Cylindrical roller bearings

C:58 mm , r max:3 mm , E:252 mm , B:58 mm
21315RHK Spherical roller bearings

(Oil) Lubrication Speed:3000 r/min , Calculation factor (Y0):2.8 , Calculation factor (Y1):2.87 , (Grease) Lubrication Speed:2200 r/min , Calculation factor (e):0.24
1215K Self aligning ball bearings

(Grease) Lubrication Speed:4300 r/min , B:25 mm , C:25 mm , Basic dynamic load rating (C):38.8 kN , Basic static load rating (C0):15.7 kN , Weight:1.36 Kg
K81240-M Thrust roller bearings

Basic dynamic load rating (C):899.7 kN , d:200 mm , Weight:3.09 Kg , D:280 mm , Dw:26 mm , Basic static load rating (C0):3149.15 kN
292/670 M Thrust roller bearings

(Grease) Lubrication Speed:482 r/min , Basic static load rating (C0):22344 kN , Basic dynamic load rating (C):4116 kN , Weight:255 Kg
B-56 Needle roller bearings

Width:0.375 Inch | 9.525 Millimeter , Manufacturer URL:http://www.koyousa.com , Bore:0.313 Inch | 7.95 Millimeter , Weight / LBS:0.01 , Manufacturer Item Number:B-56 , Outside Diameter:0.5 Inch | 12.7 Millimeter
FYR 1 3/4 Bearing units

Mass bearing unit:4.99 kg , Attachment bolt diameter G:12.7 mm , Basic dynamic load rating C:77 kN , A6:19.05 mm , N1:14.287 mm
45SBT72 Plain bearings

C:55.75 mm , d1:71.12 mm , d:114.3 mm , D:177.8 mm , B1:65.79 mm
