AST50 100IB48 AST  Material Carbon steel shell with PTFE / Fiber lining Plain bearings

AST50 100IB48 AST Material Carbon steel shell with PTFE / Fiber lining Plain bearings

Bearing numberAST50 100IB48BrandASTBore Diameter (mm)158.75Bearing TypestraightShaft Dia., Nominal (d)6.2500Shaft Size (ds) - 6.256.2475Housing Bore Dia. (Dh) - 6.43746.4358Bearing Bore after Mounting (di) - 6.2576.2502Average Clearance (Cd)0.0048Wall Thickness (S3)0.095Bearing Length, Nominal (B)3.000Bearing Length Tolerance (B tol.) - +.010 / -0.…
Contact Us Now !

Product description

AST50 100IB48 AST Material Carbon steel shell with PTFE / Fiber lining Plain bearings

Bearing numberAST50 100IB48
BrandAST
Bore Diameter (mm)158.75
Bearing Typestraight
Shaft Dia., Nominal (d)6.2500
Shaft Size (ds) – 6.256.2475
Housing Bore Dia. (Dh) – 6.43746.4358
Bearing Bore after Mounting (di) – 6.2576.2502
Average Clearance (Cd)0.0048
Wall Thickness (S3)0.095
Bearing Length, Nominal (B)3.000
Bearing Length Tolerance (B tol.) – +.010 / -0.010+.010 / 0.010
OD Chamfer Length (Co)0.072
ID Chamfer Angle (B deg.)30
ID Chamfer Length (Ci)0.031
MaterialCarbon steel shell with PTFE / Fiber lining

Cross-reference to other manufacturer’s part number

50MKM5825 Needle roller bearings

Basic static load rating (C0):82.5 kN , Weight:0.097 Kg , b:22.3 mm , Basic dynamic load rating (C):35.9 kN
3008 ZZ Angular contact ball bearings

d:40 mm , D:68 mm , Width :21mm , B1:21 mm , a:30.8 mm , C:21 mm
22214EXK Cylindrical roller bearings

Calculation factor (Y0):2.8 , (Oil) Lubrication Speed:5300 r/min , Calculation factor (e):0.24 , Calculation factor (Y1):2.87
XAB32010X/YKB32010X Tapered roller bearings

Dynamic load rating radial (C):69.8 kN , Weight:0.41 Kg , r:0.5 mm , Calculation factor (e):0.42
YET205 Deep groove ball bearings

s1:23.5 mm , r2 min.:0.6 mm , Fatigue load limit (Pu):0.335 , Weight:0.18 Kg , Basic static load rating (C0):7.8 kN , Basic dynamic load rating (C):14 kN
NKXR30 Complex bearings

D:42.000 mm , Fw:30.000 mm , Outer Diameter :42.000mm , Width :30.000mm , C:30.000 mm
3220 Angular contact ball bearings

Weight:6.1 Kg , a:118 mm , Basic static load rating (C0):173 kN , C:60.3 mm , (Grease) Lubrication Speed:2320 r/min , Basic dynamic load rating (C):157 kN
24124EAW33 Thrust roller bearings

D:200.000 mm , Width :80.000mm , d:120.000 mm , H:80.000 mm
VEX 10 /NS 7CE1 Angular contact ball bearings

(Oil) Lubrication Speed:165 000 r/min , Weight:0.017 Kg , Basic dynamic load rating (C):3.02 kN , (Grease) Lubrication Speed:109 000 r/min , Basic static load rating (C0):1.18 kN
16007-2Z Deep groove ball bearings

C:9 mm , B:9 mm , Basic static load rating (C0):6.6 kN , Basic dynamic load rating (C):9 kN , Weight:0.11 Kg
