Product description

AST650 709080 AST Bearing Outside Diameter Tolerance (Do tol.) 90 +0.035 / +0.013 Plain bearings

Bearing numberAST650 709080
BrandAST
Bore Diameter (mm)70
Outer Diameter (mm)90
Bearing Typestraight
Shaft Dia., Nominal (d)70.0000
Housing Bore Dia. (Dh) – 90 +0.035 / -090 +0.035 / 0
Bearing Outside Diameter, Nominal(Do)90.000
Bearing Outside Diameter Tolerance (Do tol.)90 +0.035 / +0.013
Bearing Bore after Mounting (di)70 +0.080 / +0.030
Bearing Length, Nominal (B)80.000
Bearing Length Tolerance (B tol.) – -0.10 / -0.300.10 / 0.30
OD Chamfer Length (Co)3.000
ID Chamfer Angle (B deg.)15
ID Chamfer Length (Ci)1.200
MaterialCast bronze with solid lubricant inserts.

Cross-reference to other manufacturer’s part number

SDE80OP Linear bearings

D1:116 mm , W:4.15 mm , L:165 mm , Basic dynamic load rating (C):8890 kN , B:133.7 mm , Weight:4.8 Kg
20210-K-TVP-C3 Spherical roller bearings

Weight:0.489 Kg , Basic dynamic load rating (C):58.5 kN , ra max.:1 mm , Fatigue load limit (Pu):7 , Basic static load rating (C0):68 kN
24124RH Spherical roller bearings

Calculation factor (Y1):1.75 , (Oil) Lubrication Speed:2200 r/min , Calculation factor (e):0.38 , (Grease) Lubrication Speed:1600 r/min , Calculation factor (Y0):1.72
2306 Self aligning ball bearings

(Grease) Lubrication Speed:9945 r/min , Weight:0.5 Kg , Basic dynamic load rating (C):30.58 kN , Basic static load rating (C0):8.62 kN
14116/14283 Tapered roller bearings

B:19.583 mm , D:72.085 mm , C:18.415 mm , T:22.385 mm , a:4.3 mm
29317 Thrust roller bearings

Minimum Buy Quantity:N/A , Product Group – BDI:B04311 , Weight / Kilogram:2.88 , Manufacturer Name:NTN
VEB 40 /S/NS 7CE3 Angular contact ball bearings

Db max:59.6 mm , Weight:0.088 Kg , (Grease) Lubrication Speed:34 000 r/min , Basic static load rating (C0):5.85 kN , rb max.:0.3 mm , Basic dynamic load rating (C):9.23 kN
LUNF 20-2LS Linear bearings

Basic dynamic load rating (C):2 kN , Weight:0.215 Kg , Thread (E):10.8 , Thread (N1):M8
YM3820P Needle roller bearings

Basic dynamic load rating (C):42 kN , Weight:0.082 Kg , C:20 mm , D:48 mm , Basic static load rating (C0):82.8 kN , Fw:38 mm
23972EK Cylindrical roller bearings

Basic static load rating (C0):2960 kN , Calculation factor (Y0):3.96 , (Oil) Lubrication Speed:1100 r/min , (Grease) Lubrication Speed:900 r/min , Calculation factor (Y1):4.05 , Calculation factor (e):0.17
