AST650 8010070 AST OD Chamfer Length (Co) 3.000  Plain bearings

AST650 8010070 AST OD Chamfer Length (Co) 3.000 Plain bearings

Bearing numberAST650 8010070BrandASTBore Diameter (mm)80Outer Diameter (mm)100Bearing TypestraightShaft Dia., Nominal (d)80.0000Housing Bore Dia. (Dh) - 100 +0.035 / -0100 +0.035 / 0Bearing Outside Diameter, Nominal(Do)100.000Bearing Outside Diameter Tolerance (Do tol.)100 +0.035 / +0.013Bearing Bore after Mounting (di)80 +0.080 / +0.030Bearing Len…
Contact Us Now !

Product description

AST650 8010070 AST OD Chamfer Length (Co) 3.000 Plain bearings

Bearing numberAST650 8010070
BrandAST
Bore Diameter (mm)80
Outer Diameter (mm)100
Bearing Typestraight
Shaft Dia., Nominal (d)80.0000
Housing Bore Dia. (Dh) – 100 +0.035 / -0100 +0.035 / 0
Bearing Outside Diameter, Nominal(Do)100.000
Bearing Outside Diameter Tolerance (Do tol.)100 +0.035 / +0.013
Bearing Bore after Mounting (di)80 +0.080 / +0.030
Bearing Length, Nominal (B)70.000
Bearing Length Tolerance (B tol.) – -0.10 / -0.300.10 / 0.30
OD Chamfer Length (Co)3.000
ID Chamfer Angle (B deg.)15
ID Chamfer Length (Ci)1.200
MaterialCast bronze with solid lubricant inserts.
