BS2-2313-2CS/VT143 SKF 65x140x56mm  Da max. 128 mm Spherical roller bearings

BS2-2313-2CS/VT143 SKF 65x140x56mm Da max. 128 mm Spherical roller bearings

Bearing numberBS2-2313-2CS/VT143Size (mm)65x140x56BrandSKFBore Diameter (mm)65Outer Diameter (mm)140Width (mm)56d65 mmD140 mmB56 mmC56 mmb8.3 mmd278.7 mmr1 min.2.1 mmr2 min.2.1 mmD1126 mmK4.5 mmda min.77 mmda max78.5 mmDa max.128 mmra max.2 mmWeight4.15 KgBasic dynamic load rating (C)340 kNBasic static load rating (C0)360 kNFatigue load limit (Pu)3…
Contact Us Now !

Product description

BS2-2313-2CS/VT143 SKF 65x140x56mm Da max. 128 mm Spherical roller bearings

Bearing numberBS2-2313-2CS/VT143
Size (mm)65x140x56
BrandSKF
Bore Diameter (mm)65
Outer Diameter (mm)140
Width (mm)56
d65 mm
D140 mm
B56 mm
C56 mm
b8.3 mm
d278.7 mm
r1 min.2.1 mm
r2 min.2.1 mm
D1126 mm
K4.5 mm
da min.77 mm
da max78.5 mm
Da max.128 mm
ra max.2 mm
Weight4.15 Kg
Basic dynamic load rating (C)340 kN
Basic static load rating (C0)360 kN
Fatigue load limit (Pu)38
Limiting speed1000 r/min
Calculation factor (e)0.35
Calculation factor (Y0)1.8
Calculation factor (Y1)1.9
